- AMD Ryzen 5 1600 comes with 6 cores 12 threads which would enable enhanced performance in applications that can make use of the available cores. Has a base clock speed of 3.2 GHz with Max Boost Clock of 3.6 GHz.
- All this paired with 19 MB of combined cache with L1 of 576KB, L2 of 3 MB, and L3 cache of 16 MB. It has a TDP rating of 65W with dual-channel DDR4 support for up-to 2667Mhz.
- It comes with simple and powerful overclocking Utility for AMD Ryzen processors and high-performance AMD wraith spire cooler is included
- MSI A320M-A PRO MAX Motherboard supports DDR4 Memory, up to 3200 (OC) MHz and 1st, 2nd and 3rd Gen AMD Ryzen, Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics, Athlon with Radeon Vega Graphics and A-series, Athlon X4 Desktop Processors for Socket AM4.
- Combined with neutral colors, such as black, grey, and silver, as the main background, MSI motherboard blends well with different RGB LED effects and strongly shows the gamer's tunes.
AMD SenseMI Technology
With AMD SenseMI technology, Ryzen processors use true machine intelligence to accelerate performance.
Zen Core Architecture
Improved energy efficiency, higher clock speeds, and more cores than ever before.
AMD Ryzen Master Utility
The simple and powerful overclocking utility for AMD Ryzen processors.
AMD Ryzen 5 for Gaming
Elite caliber experiences on competitive titles.
AMD Ryzen 5 for Streaming
Simultaneous play and capture from one powerful system.
AMD Ryzen 5 for VR
Experience smooth and responsive cutting-edge VR content.
AMD Ryzen 5 for Every Creator
Power and performance for developers and enthusiasts alike.
MSI motherboards let you manage speeds and temperatures for all your system and CPU fans. Total Fan Control allows you check your primary system characteristics in a simplified graphical interface.
MSI AM4 motherboards perfectly support AMD Ryzen processors. Combining MSI Core Boost, you can release maximum performance no matter what CPU you use.
Overclocking with XMP Profile
The XMP (Extreme Memory Profiles) in MSI BIOS is tested and certified by MSI OC lab. It is easy to enable auto power settings to get the best memory speed and stability.
The new AMD SSD technology to improve storage performance. This tool helps create a virtual SSD by blending capacity storage, treats flash as primary storage, and optimizes data access with monitoring continuously.
|Product Type||Processor and Motherboard Combo|
AMD Ryzen 5 1600 Desktop Processor
|Max. Boost Frequency||3.6GHz|
|Memory support||DDR4 2667|
|Processor Graphics||Discrete Graphics Card Required|
|PCIe Express Version||3.0 x16|
|Max Operating Temp.||95°C|
|Storage Boost Technology||FuzeDrive|
|Instruction Set Extension||AVX2, FMA3|
|Encryption Instruction Set||AES|
|Machine Learning||AMD SenseMI Technology, XFR (Extended Frequency Range)|
|Product Family||AMD Ryzen Processors|
MSI A320M-A PRO MAX Motherboard
|Model||A320M-A PRO MAX|
|Chipset||AMD A320 Chipset|
|Memory||DDR4 Memory : 1866/ 2133/ 2400/ 2667Mhz (by JEDEC)
2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz (by A-XMP OC MODE)
|On-Board Graphics support||1 x DVI-D port, supports a maximum resolution of 1920x1200 @ 60Hz
1 x HDMI 1.4 port, supports a maximum resolution of 4096x2160 @ 24Hz
|Expansion Slot||1 x PCIe 3.0 x16 slot: Supports x16 speed - 1st, 2nd and 3rd Gen AMD Ryzen, Supports x8 speed, Ryzen with Radeon Vega Graphics, 2nd Gen AMD Ryzen with Radeon Graphics, A-series, Athlon X4, Supports x4 speed, AMD Athlon with Radeon Vega Graphics
PCIe 2.0 x1 slot
|LAN||1 x Realtek 8111H|
|Storage||4 x SATA 6Gb/s ports : Supports RAID 0, RAID1 and RAID 10.
1x M.2 slot (Key M) : Supports PCIe 3.0 x4 and SATA 6Gb/s - 1st, 2nd and 3rd Gen AMD Ryzen, Ryzen with Radeon Vega Graphics, 2nd Gen AMD Ryzen with Radeon Graphics.
Supports PCIe 3.0 x2 and SATA 6Gb/s - AMD Athlon with Radeon Vega Graphics, A-series, Athlon X4 Supports 2242/2280/22110 storage devices
|Audio||Realtek ALC892 Codec : 7.1-Channel High Definition Audio|
|USB Ports||6x USB 3.2 Gen1 (SuperSpeed USB) ports (4 ports on the back panel, 2 ports available through the internal USB connector)
6x USB 2.0 (High-speed USB) ports (2 ports on the back panel, 4 ports available through the internal USB connectors)
|I/O Ports||1 x PS/2 keyboard/mouse combo port(s)
1 x DVI-D Port
4 x USB 3.2 Gen1
1 x LAN Port br> HDMI Port
2 x USB 2.0 Port
3 x HD Audio Connectors
|Internal I/O ports||1x 24-pin ATX main power connector
1x 4-pin ATX 12V power connector
4x SATA 6Gb/s connectors
2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
1x USB 3.2 Gen1 connector (supports additional 2 USB 3.2 Gen1 ports)
1x 4-pin CPU fan connecto
1x 4-pin system fan connector
1x Front panel audio connector
2x Front panel connectors
1x TPM module connector
1x Chassis Intrusion connector
1x Serial port connector
1x Clear CMOS jumper
1 x MSI A320M-A PRO MAX Motherboard
|Dimensions||9.3 in. x 7.9 in. (23.6 cm x 20.0 cm)
m-ATX Form Factor
