Highlights:
- ASUS TUF Gaming Z490-Plus motherboard is designed to support the latest Intel 10th Gen processors with DDR4 memory up to 128GB. The board supports Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0
- The board comes with an integrated graphics processor and supports multiple GPUs with AMD 2-Way CrossFireX Technology. With ASUS overvoltage protection the board is safe against any unexpected spikes in voltages
- The Z490-Plus features Thunderbolt 3 support enabling support up to six devices in a daisy-chain, and provide up to 100 watts of power to fast-charge devices
- The Intel Ethernet and Turbo LAN with cFosSpeed traffic-shaping technology adds even more lag-reducing support and an intuitive user interface, so you can reduce lag by up to 1.45X enabling faster file transfers, smoother lag-free gaming and high-res video streaming
TUF Gaming Z490-Plus
TUF Gaming Z490-Plus distills essential elements of the latest Intel platform and combines them with game-ready features and proven durability. With a comprehensive set of cooling options, this motherboard delivers rock-solid performance with unwavering gaming stability.
Power Design
With 6-layered PCB design, the TUF Z490-Plus is the perfect foundation for your next high-core-count battle rig. Equipped with DRMOS and ProCool sockets lower impedance is guaranteed eliminating any connection failure.
Intel Ethernet
Intel Ethernet Connection I219-V reduces CPU overhead and offers exceptionally high TCP and UDP throughput for faster, smoother data transfer.
Cooling
The board comes with an optimized cooling setup. Intelligent controls let you manage to cool easily, giving you everything you need to harness the full potential of your build for top-tier gaming performance.
Dual M.2
Dual M.2 slots support data-transfer speeds of up to 32 Gbps on the x4 PCI Express 3.0 bandwidth, making it perfect for OS or application drives for quicker boot-up and app load times.
Thunderbolt 3 Support
An integrated Thunderbolt 3 header supports up to 40 Gbps. One Thunderbolt 3 port can support up to six devices in a daisy-chain, and provide up to 100 watts of power to fast-charge devices.
Aura Sync
ASUS Aura offers full RGB lighting control with a variety of functional presets for the built-in RGB LEDs as well as strips connected to the onboard RGB header. It can all be synced with Aura-capable ASUS hardware.
SafeSlot
Manufactured via a new insert-molding process, SafeSlot integrates fortifying metal for an inherently stronger slot, which is then firmly anchored to the PCB through additional solder points.
ESD Guard
ESD Guards prolong the life of components while preventing damage from electrostatic discharge, providing protection for up to +/- 10 kV of air discharge and +/- 6 kV of contact discharge.
TUF LANGuard
TUF LANGuard is a military-grade innovation that integrates advanced signal-coupling technology and premium surface-mounted capacitors to improve throughput, protecting the motherboard from lightning strikes and static electricity.
Stainless Steel I/O Panel
TUF Gaming motherboards have a corrosion-resistant stainless-steel back I/O panel bonded with chromium oxide to provide a 3X-longer lifespan versus traditional panels. With this protective feature, TUF Gaming motherboards passed 72-hour salt fog testing, while other brands only passed 24-hour testing.
| Model | TUF Gaming Z490-Plus |
| CPU Socket | Intel Socket 1200 |
| CPU Support | Intel Socket 1200 for 10th Gen Intel Core, Pentium Gold and Celeron Processors Supports Intel 14 nm CPU |
| Chipset | Intel Z490 |
| Memory | 4 x DIMM, Max. 128GB, DDR4 4600(O.C)/4500(O.C)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/ 3333(O.C.)/3300(O.C.)/3200(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.)/2666/2400/2133 MHz Non-ECC, Un-buffered Memory Dual Channel Memory Architecture OptiMem 10th Gen Intel Corei9/i7 CPUs support 2933/2800/2666/2400/2133 natively |
| On-Board Graphics support | Integrated Graphics Processor 1 x DisplayPort 1.4 1 x HDMI 1.4b |
| Multi-GPU support | Supports AMD 2-Way CrossFireX Technology |
| Expansion Slot | Intel 10th Gen Processors 2 x PCIe 3.0 x16 (x16mode) Intel Z490 Chipset 1 x PCIe 3.0 x16 (x4 mode) 3 x PCIe 3.0 x1 |
| LAN | Intel I219-V 1Gb Ethernet TUF LANGuard |
| Storage | Total supports 2 x M.2 slots and 6 x SATA 6Gb/s ports Intel Z490 Chipset : 1 x M.2_1 Socket 3, with M Key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode) 1 x M.2_2 Socket 3, with M Key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode) 6 x SATA 6Gb/s port(s) Support Raid 0, 1, 5, 10 Intel Rapid Storage Technology supports Intel Optane Memory Ready |
| Audio | Realtek ALC S1200A 7.1 Surround Sound High Definition Audio CODEC - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking, up to 24-Bit/192kHz playback Audio Feature : - Optical S/PDIF out port(s) at the back panel - Audio cover - Audio Shielding - Dedicated audio PCB layers - Premium Japanese audio capacitors * Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for 8-Channel audio. |
| USB Ports | Rear USB Port ( Total 6 ) 2 x USB 3.2 Gen 2 port(s)(1 + Type-A +1 + USB Type-C) 4 x USB 3.2 Gen 1 port(s)(4 x Type-A) Front USB Port ( Total 6 ) 1 x USB 3.2 Gen 2 front panel connector port(s)(1 x USB Type-C) 1 x USB 3.2 Gen 1 port(s)(2 x Type-A) 1 x USB 2.0 port(s)(2 x Type-A) 1 x USB 2.0 port(s)(1 x Type-A) |
| I/O Ports | 1 x PS/2 keyboard/mouse combo port(s) 1 x DisplayPort 1 x HDMI 1 x LAN (RJ45) port(s) 2 x USB 3.2 Gen 2 (1 x Type-A+1 x USB Type-C) 4 x USB 3.2 Gen 1 (blue) Type-A 1 x Optical S/PDIF out 5 x Audio jack(s) |
| Internal I/O ports | 1 x CPU Fan connector(s) 1 x CPU OPT Fan connector(s) 3 x Chassis Fan connector(s) 1 x AIO_PUMP connector 2 x Aura RGB Strip Headers 1 x Addressable Gen 2 header(s) 1 x USB 3.2 Gen2 connector support additional 1 USB ports(20-pin, Type-C) 1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s) 1 x USB 2.0 connector(s) support(s) additional 1 USB 2.0 port(s) 2 x M.2 Socket 3 6 x SATA 6Gb/s connector(s) 1 x Thunderbolt header(s) 1 x 24-pin EATX Power connector(s) 1 x 8-pin ATX 12V Power connector(s) 1 x 4-pin ATX 12V Power connector(s) 1 x Front panel audio connector(s) (AAFP) 1 x System panel(s) (Chassis intrusion header is inbuilt) 1 x Clear CMOS jumper(s) 1 x COM port header 1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s) |
| Accessories | User's manual 1 x ASUS Fan Holder I/O Shield 2 x SATA 6Gb/s cable(s) 1 x M.2 Screw Package 1 x Supporting DVD 1 x TUF GAMING Sticker 1 x TUF Certification card(s) |
| Dimensions | 30.5 cm x 24.4 cm (12 x 9.6 ) ATX Form Factor |
| Warranty | 3 Years of Brand Warranty |
