Deepcool PL750D 750 Watts 80 Plus Bronze ATX 3.0 Non-Modular Power Supply Unit SMPS
Deepcool PL750D 750 Watts 80 Plus Bronze ATX 3.0 Non-Modular Power Supply Unit SMPS
Brand: DEEPCOOL
Regular price
Rs. 5,479.00
Sale price
40% off Rs. 5,479.00
Sale
Sold out
Regular price
Rs. 8,999.00
Unit price
/
per
- Free Shipping
- 7-Days Return
- Original Warranty
Product Description:
The PL750D updates DeepCool non-modular PSUs with a 12VHPWR cable and brings them into compliance with INTEL's ATX3.0 standard. These units are 80 PLUS Bronze-verified, come with a 120mm hydro-bearing fan, and will provide stable power for years to come.
NATIVE ATX3.0
Based on INTEL's latest ATX3.0 standard, the PL750D has the ability to provide twice the total system power for 0.1 ms, so power spikes will never be an issue. A native PCIe 5.0 power connector is included and has been rated up to 450 watts.
PREMIUM ELECTROLYTIC CAPACITORS
High-grade electrolytic capacitors allow the PL-D series of PSUs to keep the hold-up time to ≥ 16 ms under full load (100%), and they can easily handle power outages.
ROCK SOLID RELIABILITY
Provides reliable and stable power thanks to a well-designed dual-transistor forward topology. The PL-D utilizes active PFC and DC to DC conversion. The entire unit is made of high-quality parts and can operate at altitudes of up to 5,000 meters above sea level.
PAST, PRESENT AND FUTURE
Equipped with three PCIe, two EPS, and a 16AWG 12VHPWR cable, the PL-D PSUs provide stable and consistent power for legacy and next-generation PCs for the foreseeable future.
BOLD BRONZE
Certified 80 PLUS Bronze, ensuring at least 85% efficiency under typical loads (50%).
EXCEPTIONAL WARRANTY
Standing behind the high standards DeepCool has set for our products, a 5-year limited warranty is included to ensure worry-free service.
Type | ATX12V V3.0 |
80PLUS Certifications | 80Plus Bronze |
Fan Size | 120mm |
Fan Bearing | Hypro Bearing |
Topology | Active PFC+DC to DC |
Capacitors | Chinese Electrolytic Capacitors |
Power Good Signal | 100-500ms |
Hold Up Time | ≥16ms |
Efficiency | ≥85% Under Typical Load(50% Loading) |
Protection | OPP/OVP/SCP/OTP/OCP/UVP/SIP/NLO |
Operation Temperature | 0-40°C |
Connectors |
Main Power Connector (20+4)Pin x 1
CPU(4+4)Pin x 2 PCI-E(6+2)Pin x 1 PCI-E(6+2)Pin x 2 12VHPWR(16Pin) x 1 SATA x 3 + 4Pin Peripheral x 1 |
Regulatory |
CE/FCC/CCC/RCM/EAC/ CAN ICES-003(B)/NMB-003(B) /TUV-RH |
MTBF | 100,000 Hours |
Product Dimensions | 150×140×86mm (W x L x H) |
Warranty | 5 Year Warranty |
