ASUS ROG STRIX Z590-F WiFi Gaming motherboard is designed to support latest Intel Socket LGA1200 for 11th Gen Intel Core processors & 10th Gen Intel Core, Pentium Gold and Celeron Processors. The board is PCIe 4.0 Ready supporting up to 128GB DDR4 5333MHz(OC) of memory and Intel Turbo Boost Technology to push your gaming experience to its peak.
The latest ASUS AI-powered enhancements span four pillars of performance, including overclocking, cooling, networking and onboard audio, making advanced tweaks and optimization accessible. Intelligent software solutions help ensure that your system performs at its best.
ROG STRIX Z590-F WiFi features the most comprehensive cooling options ever that are configurable via Fan Xpert 4 or the UEFI BIOS. It employs an fan bracket, plus four M.2 sinks teamed with backplate blocks to wick heat away from critical components. That rugged foundation is backed by complimentary headers for fans, AIOs and water pump headers, paired with flexible control options that allow you to keep thermals in check at all times.
The latest connectivity solutions including WiFi 6E AX210, dual Intel 2.5 Gb Ethernet, PCIe 4.0 and two Thunderbolt USB Type-C ports ensure supersmooth networking and blisteringly fast file transfers. And for enthusiasts looking for high-fidelity audio, the SupremeFX ALC4082 codec takes gaming immersion to a whole new level while also saving a PCIe slot.
ASUS's 5-Way Optimization helps you in automated system-wide tuning, providing overclocking and cooling profiles that are tailor made for your rig.

~section~

ASUS ROG STRIX Z590-F GAMING WIFI Motherboard-From TPS Tech

ASUS ROG STRIX Z590-F GAMING WIFI Motherboard-From TPS Tech

ROG STRIX Z590-F Gaming WiFi

The flagship ROG Strix Z590-F Gaming WiFi motherboard is designed with boosted power delivery and optimized cooling to cope with the demands of powerful 11th Generation Intel Processors. This powerhouse of a motherboard is wrapped in a futuristic look that’s highlighted with a brushed-metal finish, iridescent ROG logo on the I/O shroud, and Aura Sync illumination.

ASUS ROG STRIX Z590-F GAMING WIFI Motherboard-From TPS Tech

ASUS ROG STRIX Z590-F GAMING WIFI Motherboard-From TPS Tech

Power Design

ROG Strix Z590-F Gaming WiFi is armed with up-rated power delivery and optimized cooling to enable top-tier performance for gaming. Superior chokes and durable capacitors are engineered to resist extreme temperatures and provide up to 110% better performance than the industry standard.

ASUS ROG STRIX Z590-F GAMING WIFI Motherboard-From TPS Tech

Networking

Onboard WiFi 6E technology takes advantage of the newly available radio spectrum in the 6 GHz band. It provides up to three times the bandwidth of the 5 GHz band. Dual onboard 2.5 Gb Ethernet gives a 2.5X improvement over standard Ethernet connections.

ASUS ROG STRIX Z590-F GAMING WIFI Motherboard-From TPS Tech

Cooling

The board comes with an optimized intelligent cooling setup. Intelligent controls lets you manage cooling easily, giving you everything you need to harness the full potential of your build for top-tier gaming performance. The system includes CPU fan header, AIO pump fan header and Water pump header.

ASUS ROG STRIX Z590-F GAMING WIFI Motherboard-From TPS Tech

AIDA64 Extreme

ROG Strix Z590 motherboards include a 60-day AIDA64 Extreme subscription. This industry-leading system information tool provides detailed information about installed hardware and software, and it also provides benchmarks for measuring performance of the entire system or individual components. AIDA64 Extreme includes a monitoring and diagnostics feature to detect and prevent hardware issues.

ASUS ROG STRIX Z590-F GAMING WIFI Motherboard-From TPS Tech

PCIe 4.0-Ready

Features four onboard M.2 slots, two of which support the latest PCIe 4.0 standard to provide maximum storage flexibility and the fastest data speeds available with the latest Intel processors. An M.2 backplate helps deal with the heat generated by the PCIe 4.0 SSDs. In addition, three of the M.2 slots support up to a 22110 socket and NVM Express RAID.

ASUS ROG STRIX Z590-F GAMING WIFI Motherboard-From TPS Tech

BIOS FlashBack

BIOS FlashBack is the simplest and safest way to update BIOS. Simply drop the (UEFI) BIOS file onto a FAT32-formatted USB stick, and plug it into the USB BIOS FlashBack port and press the button. Updates can even be performed without having memory or a CPU installed. A quick press of the Clr CMOS button helps reset BIOS settings.

ASUS ROG STRIX Z590-F GAMING WIFI Motherboard-From TPS Tech

Optimem III

With proprietary memory trace layout tweaks that improve signal integrity and mitigate noise, OptiMem III allows memory kits to run at lower latencies, reduced voltages, and operate at higher frequencies. Stack ROG Strix with your favorite modules and maximize the throughput of the 11th Gen Intel Core.

ASUS ROG STRIX Z590-F GAMING WIFI Motherboard-From TPS Tech

CPU Performance Boost

The Turbo Processing Unit (TPU) is an intelligent onboard micro-controller that provides an array of system-tuning features, including the ability to fine-tune voltages, monitor system stats and adjust overclocking parameters.

ASUS ROG STRIX Z590-F GAMING WIFI Motherboard-From TPS Tech

EPU

With the Energy Processing Unit (EPU) you'll enjoy system-wide power savings. The EPU automatically optimizes power consumption and maximizes savings with Away mode a smart setting that creates an extreme energy-saving scenario by shutting down unused I/O controllers.

ASUS ROG STRIX Z590-F GAMING WIFI Motherboard-From TPS Tech

Fan Xpert 4

Enjoy comprehensive control over fans, water pumps and all-in-one (AIO) coolers, via either Fan Expert 4 or our UEFI. Whether you're cooling with air or water, Auto-Tuning mode intelligently configures all parameters with a single click. There's also an Extreme Quiet mode, which reduces all fan speeds to below the default minimum keeping your system whisper-quiet when performing light tasks.

ASUS ROG STRIX Z590-F GAMING WIFI Motherboard-From TPS Tech

Digital Power Control

The Digi+ voltage-regulator module (VRM) delivers real-time control over voltage droop, switching frequency and power-efficiency settings, allowing you to fine-tune CPU voltage regulation for ultimate stability and performance.

ASUS ROG STRIX Z590-F GAMING WIFI Motherboard-From TPS Tech

Turbo Core App

Intel processors feature per-core tuning, and the ASUS Turbo app makes use of this feature by letting you assign applications to specific processor cores, prioritizing computing power where it's needed most.

ASUS ROG STRIX Z590-F GAMING WIFI Motherboard-From TPS Tech

M.2 Q-Latch

The innovative Q-Latch makes it easy to install or remove an M.2 SSD without the need for specific tools. The design employs a simple locking mechanism to secure the drive and neatly eliminate traditional screws.

ASUS ROG STRIX Z590-F GAMING WIFI Motherboard-From TPS Tech

Pre-Mounted I/O Shield

ROG's patented I/O shield is finished in sleek matte black and comes pre-mounted to make it easy to install the motherboard. The shield assures protection to your STRIX motherboard in any environment.

ASUS ROG STRIX Z590-F GAMING WIFI Motherboard-From TPS Tech

Aura Sync

ASUS Aura offers full RGB lighting control with a variety of functional presets for the built-in RGB LEDs as well as strips connected to the onboard RGB header. It can all be synced with Aura-capable ASUS hardware.

~section~

Model	ROG STRIX Z590-F GAMING WIFI (90MB1630-M0UAY0)
CPU Socket	Intel Socket LGA1200
CPU Support	Intel Socket LGA1200 for 11th Gen Intel Core processors & 10th Gen Intel Core, Pentium Gold and Celeron Processors Supports Intel 14 nm CPU Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0
Chipset	Intel Z590
Memory	DDR4 5333(OC)/5133(OC)/5000(OC)/4800(OC)/4700(OC)/4600(OC)/4500(OC)/4400(OC) /4266(OC)/4133(OC)/4000(OC)/3866(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133 MHz MHz Non-ECC, Un-buffered Memory Dual Channel Memory Architecture Supports Intel Extreme Memory Profile (XMP) OptiMem II
Expansion Slot	2 x PCIe 4.0/3.0 x16 (x16, x8/x4) + 1 x PCIe 3.0 x16 (max. x4) Intel 11th &10th Gen Processors 2 x PCIe 4.0/3.0 x16 slot(s) Intel 11th support PCIe 4.0 x16 or x8/x4 mode(s) Intel 10th processors support PCIe 3.0 x16 or x8/x4 mode(s) Intel Z590 Chipset 1 x PCIe 3.0 x16 slot (supports x4 mode)
Wireless and Bluetooth	2x2 Tri-Band Intel Wi-Fi a/b/g/n/ac/ax/az + BT5.2
Storage	Intel 11th &10th Gen Processors M.2_1 slot (Key M), type 2242/2260/2280/22110 - Only Intel 11th Core processors support PCIe 4.0 x4 mode, this slot will be disabled for other CPUs M.2_2 slot (Key M), type 2242/2260/2280/22110 - Intel 11th processors support PCIe 4.0 x4 mode - Intel 10th processors support PCIe 3.0 x4 mode Intel Z590 Chipset M.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 3.0 x4 mode) M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 & SATA modes) 6 x SATA 6Gb/s ports Raid function in Intel Rapid Storage Technology is available with either 1. Intel SSDs installed in both CPU-attached and PCH-attached slots, or 2. any other 3rd party SSDs installed in PCH-attached slots. To enable Intel Optane Memory (Hybrid Storage device), it must be installed in PCH-attached slots with Intel® Rapid Storage Technology.
Audio	- SupremeFX Shielding Technology - ALC4080 + Savitech SV3H712 AMP - Gold-plated audio jacks - Rear optical S/PDIF out port - Premium Japanese audio capacitors - Audio cover
USB Ports	Rear USB: Total 10 ports 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C) 3 x USB 3.2 Gen 2 ports (2 x Type-A + 1 x USB Type-C) 4 x USB 3.2 Gen 1 ports (4 x Type-A) 2 x USB 2.0 ports (2 x Type-A) Front USB: Total 7 ports 1 x USB 3.2 Gen 2 connector (supports USB Type-C) 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports 2 x USB 2.0 headers support additional 4 USB 2.0 ports
I/O Ports	1 x USB 3.2 Gen 2x2 port (1 x USB Type-C) 3 x USB 3.2 Gen 2 ports (2 x Type-A, 1 x USB Type-C ) 4 x USB 3.2 Gen 1 ports (4 x Type-A) 2 x USB 2.0 ports (2 x Type-A) 1 x HDMI port 1 x DisplayPort 1 x Intel Wi-Fi 6E 1 x Intel I225-V 2.5Gb Ethernet 5 x Gold-plated audio jacks 1 x Optical S/PDIF out port 1 x BIOS FlashBack button 1 x Clear CMOS button
Internal I/O ports	Fan and Cooling related 1 x 4-pin CPU Fan header 1 x 4-pin CPU OPT Fan header 1 x 4-pin AIO Pump header 3 x 4-pin Chassis Fan headers 1 x VRM heatsink Fan header 1 x W_PUMP+ header Power related 1 x 24-pin Main Power connector 1 x 8-pin +12V Power connector 1 x 4-pin +12V Power connector Storage related 4 x M.2 slots (Key M) 6 x SATA 6Gb/s ports USB 1 x USB 3.2 Gen 2 connector (supports USB Type-C) 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports 2 x USB 2.0 headers support additional 4 USB 2.0 ports Miscellaneous 3 x AURA Addressable Gen 2 headers 1 x AURA RGB header 1 x CPU Over Voltage jumper 1 x Front Panel Audio header (AAFP) 1 x SPI TPM header (14-1pin) 1 x 20-3 pin System Panel header with Chassis intrude function 1 x Thermal Sensor header 1 x Thunderbolt header
Accessories	Cables 4 x SATA 6Gb/s cables Additional Cooling Kit 1 x Fan holder Miscellaneous 1 x ASUS 2x2 Dual-Band Wi-Fi moving antennas 1 x M.2 Q-Latch package 2 x M.2 Rubber Packages 1 x ROG key chain 1 x cable tie 1 x ROG STRIX stickers 1 x ROG STRIX thank you card Installation Media 1 x Support DVD Documentation 1 x User manual
Dimensions	30.5 cm x 24.4 cm (12 x 9.6 inch ) ATX Form Factor
Warranty	3 Years of Brand Warranty
