Cooler Master brings in their one of a kind full-tower cabinet with MasterFrame 700. The cabinet is a highly customizable open-air frame that can convert between a showcase PC chassis or a highly flexible test bench. it features a 3-part design consisting of two side wings and a fully featured motherboard tray.
The open-air nature of the design provides unrestricted access to fresh air to all components in the system. The optional fan mounts allow to further guide the airflow path to a specific intake/exhaust direction, thus preventing performance-robbing heat recirculation.
For its size, MasterFrame 700 sports an unmatched level of hardware compatibility. It is designed to fit any component available, even oversized ones. Users can mount up to SSI-EEB motherboards, multiple power supplies and multiple radiators at the same time and still have room for triple slots GPUs and storage.
Designed with water-cooling in mind, MasterFrame 700 provides a flexible pump and reservoir mounting location and support for multiple triple-fan radiators. The oversized panoramic tempered glass offers a greater viewing angle on the components of the system and, together with hardware-centric design of MasterFrame 700, it is the perfect way to showcase high-end components and custom cooling solutions.
The MasterFrame 700 can be wall mounted thanks to the inclusion of a 100mm x 100mm VESA mount. Perfect to showcase custom loops and high-end components. It is highly recommended to only wall mount systems below 14Kg in total. Heavy duty hinges hold the side wings to the mid-frame and allow for smooth repositioning at any angle depending on the user’s needs.

~section~

Cooler Master MasterFrame 700 Full-Tower Cabinet - From TPSTech

Cooler Master MasterFrame 700 Full-Tower Cabinet - From TPSTech

In a Class By Itself

The MasterFrame 700 is a highly customizable open-air frame that can convert between a showcase PC chassis or a highly flexible test bench. MasterFrame 700 features a 3-part design consisting of two side wings and a fully featured motherboard tray.

MSI GF63 Thin 10SCSR-660IN 15.6-Inch FHD Gaming Laptop - From TPSTech

Open-Air Frame Mode

The MasterFrame 700 stands vertically to best display the components behind its panoramic tempered glass screen. The chassis offers an unmatched level of hardware compatibility, allowing for easy-fitting of oversized components.

MSI GF63 Thin 10SCSR-660IN 15.6-Inch FHD Gaming Laptop - From TPSTech

Test Bench Mode

The side wings can fold down towards the CPU socket and GPU areas to allow to localize the airflow to the components, especially useful when overclocking. The wings also serve as spots to hold triple-fan radiators and other accessories, and thanks to their full range of mobility, swapping components while keeping the cooling solution in place is now easier than ever.

Cooler Master MasterFrame 700 Full-Tower Cabinet - From TPSTech

Motherboard and PSU Support

MasterFrame 700 allows you to mount any motherboard in the consumer market, even going so far as to support 14x14" SSI-EEB motherboards. Double support for ATX power supplies is available on the back, for systems that need double power supply.

Cooler Master MasterFrame 700 Full-Tower Cabinet - From TPSTech

Storage Support

MasterFrame 700 introduces an innovative, fully tool-less system that allows you to mount up to 4x 3.5" drives and up to 7x 2.5" drives. It is also possible to mount up to 2x 280/360mm radiators in "Open-Air" mode on the two side wings and a third radiator up to 360/420mm in "Test-Bench" mode.

Cooler Master MasterFrame 700 Full-Tower Cabinet - From TPSTech

Cooling Support

With MasterFrame 700 users are able to install up to 2x 280/360mm radiators in "Open-Air" mode (on the two side wings) and a third 360/420mmradiator while in "Test-Bench" mode, in the proximity of the CPU socket.

Cooler Master MasterFrame 700 Full-Tower Cabinet - From TPSTech

Panoramic Tempered Glass

The oversized panoramic tempered glass offers a greater viewing angle on the components of the system and, together with hardware-centric design of MasterFrame 700, it is the perfect way to showcase high-end components and custom cooling solutions.

Cooler Master MasterFrame 700 Full-Tower Cabinet - From TPSTech

Vesa Mount Compatible

The MasterFrame 700 features 100mm x 100mm VESA mount compatibility, allowing it to be wall-mounted. Perfect to showcase custom loops and high-end components. It is highly recommended to only wall mount full systems below 14Kg in total and check VESA weight standards.

Cooler Master MasterFrame 700 Full-Tower Cabinet - From TPSTech

Open Air Design

The open-air nature of the design provides unrestricted access to fresh air to all components in the system. The optional fan mounts allow to further guide the airflow path to a specific intake/exhaust direction, thus preventing performance-robbing heat recirculation.

Cooler Master MasterFrame 700 Full-Tower Cabinet - From TPSTech

Designed for Customization

The MasterFrame 700 is designed with customization in mind. The 3-parts frame can be easily disassembled easily for painting, wrapping and other modifications.

~section~

Model	MCF-MF700-KGNN-S00
Dimensions	702 x 306 x 410mm
Form Factor	Full-Tower
Materials	Steel and Tempered Glass
Mainboard Support	SSI EEB SSI CEB XL-ATX E-ATX ATX Micro ATX Mini ITX
I/O Ports	2x USB 3.1 Gen 2 Type-A 1x USB 3.2 Gen 2 Type-C 1x 3.5mm Headset Jack (Audio+Mic)
Side Panel	Tempered Glass
Expansion & Drive Bays
Expansion Slots	8
5.25 Inch	NIL
3.5 Inch / 2.5 Inch	Up to 4 (PSU cover)
2.5 Inch	7 (3 SSD brackets + 4 PSU cover)
Fan Support
Right Side	3x 120mm / 2x 140mm
Left Side	3x 120mm / 2x 140mm
Radiator Support
Right Side	Up to 280/360mm
Top	Up to 360/420mm
Left Side	Up to 280/360mm
Clearance
Max GPU Length	Up to 450mm
Max CPU Cooler Height	158mm /td>
Max PSU Height	210mm
Miscellaneous
Power Supply Support	2x ATX
Warranty	2 Years of Brand Warranty
