ASUS ROG STRIX Z690-E WIFI Gaming motherboard is designed to support latest Intel Socket LGA 1700 for 12th Gen Intel Core processors and Pentium Gold and Celeron Processors.
The board is PCIe 4.0 Ready supporting up to 128GB DDR5 6400MHz(OC) of memory and Intel Turbo Boost Technology to push your gaming experience to its peak. The board support next gen PCIe 5.0 video-cards making it future prrof.
Enjoy extended connectivity with the next-gen technology of WIFI 6E, PCIe 5.0, Realtek 2.5Gb Ethernet, USB 3.2 Gen 2x2 Type-C, PCIe Slot Q-Release, Five M.2 slots (including two on the bundled ROG Hyper M.2 card) and Thunderbolt 4 header support.
Features the most comprehensive cooling options with VRM heatsink, Thermal pads, M.2 Heatsink, M.2 backplate and hybrid fan headers. This motherboard offers rock-solid and stable performance for marathon gaming.
The latest ASUS AI-powered enhancements span four pillars of performance, including overclocking, cooling, networking and onboard audio. Intelligent software solutions help ensure that your system performs at its best.

~section~

ASUS ROG STRIX Z690-E Gaming WIFI Intel 12th Gen LGA 1700 ATX Motherboard - From TPSTech

ASUS ROG STRIX Z690-E Gaming WIFI Intel 12th Gen LGA 1700 ATX Motherboard - From TPSTech

ROG STRIX Z690-E GAMING WIFI

ROG Strix Z690-E Gaming WiFi offers premium-grade power delivery and cooling to unleash the full force of 12th Gen Intel Core processors. Framerates and load times can be boosted even further by all-new support for DDR5 memory and PCIe 5.0 video cards.

ASUS ROG STRIX Z690-E Gaming WIFI Intel 12th Gen LGA 1700 ATX Motherboard - From TPSTech

ASUS ROG STRIX Z690-E Gaming WIFI Intel 12th Gen LGA 1700 ATX Motherboard - From TPSTech

Five PCIe 4.0 M.2 Slots

With five strategically placed M.2 slots, ROG Strix Z690-E Gaming WiFi leverages mighty CPU and chipset bandwidth to deliver lightning-fast PCIe 4.0 data transfers that blaze past traditional SATA-based SSDs.

ASUS ROG STRIX Z690-E Gaming WIFI Intel 12th Gen LGA 1700 ATX Motherboard - From TPSTech

WIFI 6E

Onboard WiFi 6E technology provides up to three times the bandwidth of the 5 GHz band and up to seven 160 MHz bands to deliver ultrafast wireless networking speeds and improved capacity in dense wireless environments.

ASUS ROG STRIX Z690-E Gaming WIFI Intel 12th Gen LGA 1700 ATX Motherboard - From TPSTech

DDR5 Overclocking

For DDR5, the Strix Z690 lineup breaks performance limits by providing a stacked suite of overclocking parameters for not only high-speed kits, but even entry-level memory modules that have a locked power management IC.

ASUS ROG STRIX Z690-E Gaming WIFI Intel 12th Gen LGA 1700 ATX Motherboard - From TPSTech

AURA Sync

ROG Strix motherboards deliver sterling performance and superior aesthetics to outshine the competition. They also feature built-in ASUS Aura technology that enables full RGB lighting control and a variety of presets for embedded RGB LEDs and third-party lighting strips that can connect to onboard RGB headers.

ASUS ROG STRIX Z690-E Gaming WIFI Intel 12th Gen LGA 1700 ATX Motherboard - From TPSTech

PCIe Slot Q-Release

A physical button unlocks the first PCIe slot’s security latch with one tap, greatly simplifying the process of detaching a PCIe card from the motherboard when it’s time to upgrade to a new GPU or other compatible device.

ASUS ROG STRIX Z690-E Gaming WIFI Intel 12th Gen LGA 1700 ATX Motherboard - From TPSTech

M.2 Q-Latch

The innovative Q-Latch makes it easy to install or remove an M.2 SSD without the need for specific tools. The design employs a simple locking mechanism to secure the drive and neatly eliminate traditional screws.

ASUS ROG STRIX Z690-E Gaming WIFI Intel 12th Gen LGA 1700 ATX Motherboard - From TPSTech

BIOS Flashback

This is the simplest and safest way to update BIOS. Simply drop the (UEFI) BIOS file onto a FAT32-formatted USB stick, and plug it into the USB BIOS FlashBack port and press the button. Updates can be done in absence of memory or a CPU.

ASUS ROG STRIX Z590-E GAMING WIFI Motherboard-From TPS Tech

CPU Performance Boost

The Turbo Processing Unit (TPU) is an intelligent onboard micro-controller that provides an array of system-tuning features, including the ability to fine-tune voltages, monitor system stats and adjust overclocking parameters.

ASUS ROG STRIX Z590-E GAMING WIFI Motherboard-From TPS Tech

EPU

With the Energy Processing Unit (EPU) you'll enjoy system-wide power savings. The EPU automatically optimizes power consumption and maximizes savings with Away mode a smart setting that creates an extreme energy-saving scenario by shutting down unused I/O controllers.

ASUS ROG STRIX Z590-E GAMING WIFI Motherboard-From TPS Tech

Fan Xpert 4

Enjoy comprehensive control over fans, water pumps and all-in-one (AIO) coolers, via either Fan Expert 4 or our UEFI. Whether you're cooling with air or water, Auto-Tuning mode intelligently configures all parameters with a single click. There's also an Extreme Quiet mode, which reduces all fan speeds to below the default minimum keeping your system whisper-quiet when performing light tasks.

ASUS ROG STRIX Z590-E GAMING WIFI Motherboard-From TPS Tech

Digital Power Control

The Digi+ voltage-regulator module (VRM) delivers real-time control over voltage droop, switching frequency and power-efficiency settings, allowing you to fine-tune CPU voltage regulation for ultimate stability and performance.

ASUS ROG STRIX Z590-E GAMING WIFI Motherboard-From TPS Tech

Turbo Core App

Intel processors feature per-core tuning, and the ASUS Turbo app makes use of this feature by letting you assign applications to specific processor cores, prioritizing computing power where it's needed most.

ASUS ROG STRIX Z690-E Gaming WIFI Intel 12th Gen LGA 1700 ATX Motherboard - From TPSTech

AIDA64 Extreme

ROG Strix Z560 motherboards include a 60-day AIDA64 Extreme subscription. The tool provides detailed benchmarks for measuring performance of the entire system or individual components. AIDA64 Extreme includes a monitoring and diagnostics feature to detect and prevent hardware issues.

~section~

Model	ASUS ROG STRIX Z690-E GAMING WIFI ATX Motherboard
Part Number	90MB18J0-M0UAY0
CPU Socket	Intel Socket LGA 1700
CPU Support	Intel Socket LGA1700 for 12th Gen Intel Core, Pentium Gold and Celeron Processors Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0
Chipset	Intel Z690
Memory	4 x DIMM, Max. 128GB, DDR5 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800 Non-ECC, Un-buffered Memory Dual Channel Memory Architecture Supports Intel Extreme Memory Profile (XMP) OptiMem II
On-Board Graphics support	1 x DisplayPort 1 x HDMI
Expansion Slot	Intel 12th Gen Processors 1 x PCIe 5.0 x16 slot Intel Z690 Chipset 1 x PCIe 4.0 x16 slot (supports x4 mode or x4/x4 mode for ROG HYPER M.2 CARD) 1 x PCIe 3.0 x16 slot (supports x4 mode) 1 x PCIe 3.0 x1 slot
Ethernet	1 x Intel 2.5Gb Ethernet ASUS LANGuard
Wireless and Bluetooth	2x2 Tri-Band Intel Wi-Fi a/b/g/n/ac/ax/az + BT5.2 Wi-Fi 6E 2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax) Supports 2.4/5/6GHz frequency band* Bluetooth v5.2 hardware ready** * WiFi 6E 6GHz regulatory may vary between countries, and function will be ready in Windows 11 or later. ** Bluetooth v5.2 function will be ready in Windows 11 or later.
Storage	Total supports 3 x M.2 slots and 6 x SATA 6Gb/s ports Intel 12th Gen Processors: M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode) - Intel 12th Gen processors support PCIe 5.0 x4 mode. M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode) - Intel 12th Gen processors support PCIe 4.0 x4 mode Hyper M.2_1 slot (Key M) via Hyper M.2 card, type 2242/2260/2280/22110 - Intel 12th Gen processors support PCIe 4.0 x4 mode Intel Z690 Chipset: M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode & SATA modes) Hyper M.2_1 slot (Key M) via Hyper M.2 card, type 2242/2260/2280/22110 (suppports PCIe 4.0 x4 mode) Hyper M.2_2 slot (Key M) via Hyper M.2 card, type 2242/2260/2280/22110 (suppports PCIe 4.0 x4 mode) 6 x SATA 6Gb/s ports
Audio	ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080 - Impedance sense for front and rear headphone outputs - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking - High quality 120 dB SNR stereo playback output and 113 dB SNR recording input - Supports up to 32-Bit/384 kHz playback
USB Ports	Rear USB (Total 12 ports): 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C) 3 x USB 3.2 Gen 2 ports (2 x Type-A + 1 x USB Type-C) 4 x USB 3.2 Gen 1 ports (4 x Type-A) 4 x USB 2.0 ports (4 x Type-A) Front USB (Total 7 ports): 1 x USB 3.2 Gen 2 connector (supports USB Type-C) 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports 2 x USB 2.0 headers support additional 4 USB 2.0 ports
Internal I/O ports	Fan and Cooling related: 1 x 4-pin CPU Fan header 1 x 4-pin CPU OPT Fan header 1 x 4-pin AIO Pump header 5 x 4-pin Chassis Fan headers Power related: 1 x 24-pin Main Power connector 1 x 8-pin +12V Power connector USB: 1 x USB 3.2 Gen 2 connector (supports USB Type-C) 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports 2 x USB 2.0 headers support additional 4 USB 2.0 ports Miscellaneous: 3 x Addressable Gen 2 headers 1 x AURA RGB header 1 x BMC header 1 x CPU Over Voltage jumper 1 x Front Panel Audio header (AAFP) 1 x SPI TPM header (14-1pin) 1 x 20-3 pin System Panel header with Chassis intrude function 1 x Thermal Sensor header 1 x Thunderbolt header
Accessories	Cables: 4 x SATA 6Gb/s cables ROG HYPER M.2 CARD 1 x ROG HYPER M.2 CARD Miscellaneous: 1 x ASUS 2x2 Dual-Band Wi-Fi moving antennas 1 x M.2 Q-Latch package 1 x M.2 Q-Latch package for M.2 backplate 2 x M.2 Rubber Packages 2 x M.2 Screw Packages 1 x ROG Graphics card holder 1 x ROG key chain 1 x cable tie 1 x ROG STRIX stickers 1 x ROG STRIX thank you card Installation Media: 1 x Support DVD Documentation: 1 x User manual
Operating System	Windows 11 64-bit Windows 10 64-bit
Dimensions	30.5 cm x 24.4 cm ATX Form Factor
Warranty	3 Years of Brand Warranty
