NZXT H3 Flow Tempered Glass Micro-ATX Airflow Case
NZXT H3 Flow Tempered Glass Micro-ATX Airflow Case
Couldn't load pickup availability
- Free Shipping (optional Express Shipping)
- Comes with 7-Days Returns Policy
- Original Brand Warranty
Product Description:
Space-Saving Micro-ATX Design – Compact yet powerful, the H3 Flow supports high-performance components in a space-efficient layout ideal for modern builds.
High-Airflow Mesh Panels – Ultra-fine steel mesh on the front, top, and PSU shroud ensures maximum airflow while effectively filtering dust.
Extensive Cooling Support – Accommodates up to 7 fans, 280mm radiator in front, and 240mm radiator on top for superior thermal performance.
Full-Size GPU Compatibility – Supports graphics cards up to 377mm (without front fans), 352mm (with front fans), and 317mm (with front radiator and fans).
Pre-Installed Rear Fan – Includes 1 × 120mm F120Q (CV) fan at the rear for efficient out-of-the-box cooling.
Back-Connect Ready – Compatible with ASUS BTF and MSI Project Zero motherboards for a clean, cable-free aesthetic.
Tool-Free Access – Removable top, front, and side panels make upgrades and cleaning easy without tools.
Tempered Glass Side Panel – Showcases your build with a sleek, modern look.
Modern Front I/O – Includes 1 × USB 3.2 Gen 2 Type-C, 1 × USB 3.2 Gen 1 Type-A, and power button (no audio jack).
Simplified Cable Management – Integrated cable channels and tie-down points help keep your build neat and organized.
| Specification | Details |
| Model Numbers | CC-H31FB-01 (Black), |
| Case Type | Micro-ATX Mini Tower |
| Material | SGCC Steel, Tempered Glass |
| Color Options | Black |
| Motherboard Support | Micro-ATX, Mini-ITX |
| Dimensions (L × W × H) | 400 × 225 × 389 mm (15.75 × 8.86 × 15.31 in) |
| Weight | 4.8 kg (10.58 lbs) |
| Drive Bays | 1 × 3.5", 3 × 2.5" |
| Expansion Slots | 4 |
| Cooling Support | Up to 7 fans: Front (2 × 140mm or 3 × 120mm), Top (2 × 120/140mm), Rear (1 × 120mm), Bottom (1 × 120mm) |
| Pre-installed Fans | 1 × 120mm F120Q (CV) rear fan |
| Radiator Support | Front: up to 280mm, Top: up to 240mm |
| Maximum GPU Length | 377 mm (no front fans), 352 mm (with front fans), 317 mm (with front radiator + fans) |
| Maximum CPU Cooler Height | 170 mm |
| Maximum PSU Length | 185 mm |
| Power Supply Mount | Bottom-mount, ATX |
| Front I/O Ports | 1 × USB 3.2 Gen 2 Type-C, 1 × USB 3.2 Gen 1 Type-A (No audio jack) |
| Side Panel | Tempered Glass (tinted or clear depending on color) |
| Tool-Free Access | Yes – top, front, and side panels |
| Cable Management | Integrated channels, tie-down points |
| Back-Connect Ready | Compatible with ASUS BTF & MSI Project Zero motherboards |
| Warranty | 2 Years from Brand |
