The polygonal mesh design featuring a three-dimensional contour that’s not only aesthetical but is capable of simultaneously providing high airflow and dust filtration.
It supports Mini-ITX, Micro-ATX, ATX, SSI CEB, E-ATX (up to 12” x 10.7” motherboards). Support for up to seven 120mm fans and 360mm front and top radiator and rear liquid cooling too.
It can take up-to two 360mm radiators on the top and front panel to keep the most extreme systems cool enabling stable performance even during peak usage.
With 2 x 3.5’’/2.5’’ Combo HDD and 4 (2 + 2) x 2.5’’ SSD drive bays. Supports up to a 410mm graphics card, a 165mm CPU cooler, and up to a 180mm PSU in length enabling room for upgrades.
Three pre-installed 120mm addressable RGB fans flood the Polygonal Mesh front panel with lighting while providing considerable airflow to the system.

~section~

CoolerMaster_Masterbox_TD500_Mesh_from_the_peripheral_store_01

CoolerMaster_Masterbox_TD500_Mesh_from_the_peripheral_store

Polygonal Mesh

Crafted from Cooler Master’s Fine Mesh technology, Polygonal Mesh features a threedimensional contour and is also capable of simultaneously providing high airflow and dust filtration.

Crystalline Tempered Glass

A crystalline design spans the edges of the tempered glass side panel, precision engineered for strength as well as aesthetics.

Triple ARGB Fans

Three addressable RGB fans flood the Polygonal Mesh front panel with lighting while providing considerable airflow to the system.

Dual 360mm Radiator Support

For enthusiast-grade cooling, two 360mm radiators are supported on the top and front panel to keep the most extreme systems cool.

Versatile Cooling Options

Support for up to seven 120mm fans and front, top, and rear liquid cooling ensure the utmost in performance.

Room For Upgrades

Support for up to a 410mm graphics card, a 165mm CPU cooler, and up to a 180mm PSU in length provides room for upgrades to stay ahead of the game.

~section~

Model	MASTERBOX TD500 MESH
Dimensions	493 x 217 x 469mm
Form Factor	Full Tower
Materials	Exterior : Steel, Mesh, Plastic Left Side : Tempered Glass
Motherboard Support	Mini-ITX, Micro-ATX, ATX, SSI CEB, E-ATX* (*up to 12” x 10.7” motherboards)
I/O Ports	USB Ports : 2 x USB 3.2 Gen 1 (USB 3.0) Audio : 1 x 3.5mm Audio Jack : 1 x 3.5mm Mic Jack Other : 1 x ARGB Controller, 1 x ARGB 2-to-3 Splitter (With controller) 1 x ARGB 2-to-3 Splitter (Without controller)
Side Panel	Tempered Glass
Expansion & Drive Bays
Expansion Slots	7
3.5 Inch / 2.5 Inch	2
Fan Support
Front	3 x 120mm 2 x 140mm
Top	3 x 120mm 2 x 140mm
Rear	1 x 120mm
Pre-Installed Fan	3
Fan RGB Effect	ARGB
Radiator Support
Front	120 / 140 / 240/ 280 / 360mm
Top	120 / 240 / 360mm(44mm max motherboard component height)
Rear	120mm
Clearance
Max GPU Length	410mm / 16.10"
Max CPU Height	165mm / 6.49"
Max PSU Height	180mm / 7.08" (295mm / 11.61” withHDD cage removed)
Miscellaneous
Dust Filters	Front, Top, Bottom
Net Weight	6.95 kg
Gross Weight	8.30 kg
Warranty	2 Years of standard warranty
Package Contents	MASTERBOX TD500 MESH MCB-D500D-KGNN-S01 1N
