ASUS ROG MAXIMUS XIII Hero Z590 Gaming motherboard is designed to support Intel Socket LGA 1200 for 11th Gen Intel Core processors & 10th Gen Intel Core, Pentium Gold and Celeron Processors. The board is PCIe 4.0 Ready supporting up to 128GB DDR4 5333MHz(OC) of memory and Intel Turbo Boost Technology to push your gaming experience to its peak.
The board supports multiple GPUs with the help NVIDIA 2-Way SLI Technology. The latest ASUS AI-powered enhancements span four pillars of performance, including overclocking, cooling, networking and onboard audio, making advanced tweaks and optimization accessible. Intelligent software solutions help ensure that your system performs at its best.
ROG Maximus XIII Hero features the most comprehensive cooling options ever. It employs an enlarged cooling array for the VRM and chipset, plus four M.2 sinks teamed with backplate blocks to wick heat away from critical components. That rugged foundation is backed by complimentary headers for fans, AIOs and liquid loops, paired with flexible control options that allow you to keep thermals in check at all times.
The latest connectivity solutions including WiFi 6E AX210, dual Intel 2.5 Gb Ethernet, PCIe 4.0 and two Thunderbolt USB Type-C ports ensure supersmooth networking and blisteringly fast file transfers. And for enthusiasts looking for high-fidelity audio, the SupremeFX ALC4082 codec takes gaming immersion to a whole new level while also saving a PCIe slot.
ASUS's 5-Way Optimization helps you in automated system-wide tuning, providing overclocking and cooling profiles that are tailor made for your rig.

~section~

ASUS Z590 ROG MAXIMUS XIII Hero Gaming Motherboard-From TPS Tech

ASUS Z590 ROG MAXIMUS XIII Hero Gaming Motherboard-From TPS Tech

MAXIMUS XIII HERO

ROG Maximus XIII Hero continues to build on the legacy of its predecessors by packing upgraded power, smart cooling and lightspeed connectivity under a stealthy exterior. Bristling with renowned ROG features such as AI-enhanced controls and customizable Aura Sync illumination, the latest Hero is ready to take the helm of your high-end gaming build.

ASUS Z590 ROG MAXIMUS XIII Hero Gaming Motherboard-From TPS Tech

ASUS Z590 ROG MAXIMUS XIII Hero Gaming Motherboard-From TPS Tech

ASUS OptiMem III

With proprietary memory trace layout tweaks that improve signal integrity and mitigate noise, OptiMem III allows memory kits to run at lower latencies, reduced voltages, and operate at higher frequencies. Stack ROG Maximus XIII Hero with your favorite modules and maximize the throughput of the 11th Gen Intel Core.

ASUS Z590 ROG MAXIMUS XIII Hero Gaming Motherboard-From TPS Tech

Heatinks

ROG Maximus XIII Hero employs an enlarged cooling array for the VRM and chipset, plus four M.2 sinks teamed with backplate blocks to wick heat away from critical components. That rugged foundation is backed by A dedicated chipset heatsink which draws heat away to maintain optimum operating temperatures.

ASUS Z590 ROG MAXIMUS XIII Hero Gaming Motherboard-From TPS Tech

Coolers

The rugged foundation is backed by complimentary headers for fans, AIOs and liquid loops, paired with flexible control options that allow you to keep thermals in check at all times. Dual water-temperature headers and a flow-rate header feed information straight into the AI Suite utility, allowing you to track coolant temperatures and the flow rate of the entire loop.

ASUS Z590 ROG MAXIMUS XIII Hero Gaming Motherboard-From TPS Tech

Performance

With tailored power delivery and support for the latest high-performance memory, ROG Maximus XIII Hero easily handles the increased demands of Intel Rocket Lake processors. It features an intelligent VRM design that’s rated for 90 amps, plus quality components and memory layout optimizations to cater to enthusiasts looking to create a battle-ready rig with balanced performance.

ASUS Z590 ROG MAXIMUS XIII Hero Gaming Motherboard-From TPS Tech

Intel Wi-Fi 6E (Gig+)

Onboard WiFi 6E technology takes advantage of the newly available radio spectrum in the 6 GHz band, providing up to three times the bandwidth of the 5 GHz band. Onboard Intel 2.5 Gb Ethernet gives your wired connection a boost, with speeds that are 2.5 times faster than standard Ethernet.

ASUS Z590 ROG MAXIMUS XIII Hero Gaming Motherboard-From TPS Tech

PCIe 4.0 Ready

ROG Maximus XIII Hero is equipped with four onboard M.2 slots, with two offering PCIe 4.0 support for the latest GPUs and high-speed SSDs.

ASUS Z590 ROG MAXIMUS XIII Hero Gaming Motherboard-From TPS Tech

SupremeFX

The ALC4082 codec uses a USB interface instead of the conventional high definition audio (HDA) interface and improves playback audio resolution from 192 to 384 kHz. The technology delivers an exceptional 113 dB signal-to-noise ratio on the line-in connection to provide best-ever recording quality.

ASUS Z590 ROG MAXIMUS XIII Hero Gaming Motherboard-From TPS Tech

Accurate Voltage Monitoring

Conventional motherboards use single-ended sensing tapped from a location that isn't ideal, leading to a large disparity between the actual voltage fed to the CPU and the value reported to software. ROG Maximus XIII Hero features a differential-sensing circuit and delicate IC that simplify overclocking and tuning by allowing you to track voltages more accurately.

ASUS Z590 ROG MAXIMUS XIII Hero Gaming Motherboard-From TPS Tech

CPU Performance Boost

The Turbo Processing Unit (TPU) is an intelligent onboard micro-controller that provides an array of system-tuning features, including the ability to fine-tune voltages, monitor system stats and adjust overclocking parameters.

ASUS Z590 ROG MAXIMUS XIII Hero Gaming Motherboard-From TPS Tech

EPU

With the Energy Processing Unit (EPU) you'll enjoy system-wide power savings. The EPU automatically optimizes power consumption and maximizes savings with Away mode a smart setting that creates an extreme energy-saving scenario by shutting down unused I/O controllers.

ASUS Z590 ROG MAXIMUS XIII Hero Gaming Motherboard-From TPS Tech

Fan Xpert 4

Enjoy comprehensive control over fans, water pumps and all-in-one (AIO) coolers, via either Fan Expert 4 or our UEFI. Whether you're cooling with air or water, Auto-Tuning mode intelligently configures all parameters with a single click. There's also an Extreme Quiet mode, which reduces all fan speeds to below the default minimum keeping your system whisper-quiet when performing light tasks.

ASUS Z590 ROG MAXIMUS XIII Hero Gaming Motherboard-From TPS Tech

Digital Power Control

The Digi+ voltage-regulator module (VRM) delivers real-time control over voltage droop, switching frequency and power-efficiency settings, allowing you to fine-tune CPU voltage regulation for ultimate stability and performance.

ASUS Z590 ROG MAXIMUS XIII Hero Gaming Motherboard-From TPS Tech

Turbo Core App

Intel processors feature per-core tuning, and the ASUS Turbo app makes use of this feature by letting you assign applications to specific processor cores, prioritizing computing power where it's needed most.

~section~

Model	ROG MAXIMUS XIII HERO (90MB15X0-M0UAY0)
CPU Socket	Intel Socket LGA 1200
CPU Support	Intel Socket LGA1200 for 11th Gen Intel Core processors & 10th Gen Intel Core, Pentium Gold and Celeron Processors Supports Intel 14 nm CPU Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0
Chipset	Intel Z590
Memory	4 x DIMM, Max. 128GB, DDR4 5333(OC)/5133(OC)/5000(OC)/4800(OC)/4700(OC)/4600(OC)/4500(OC)/ 4400(OC)/4266(OC)/4133(OC)/4000(OC)/3866(OC)/ 3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/ 3000/2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory Dual Channel Memory Architecture Supports Intel Extreme Memory Profile (XMP) OptiMem III
Multi-GPU support	Supports NVIDIA 2-Way SLI Technology
Expansion Slot :	Intel 11th &10th Gen Processors 2 x PCIe 4.0/3.0 x16 slot(s) - Intel 11th Core processors support PCIe 4.0 x16 or x8/x8 or x8/x4 mode(s) - Intel10th Core processors support PCIe 3.0 x16 or x8/x8 or x8/x4 mode(s) Intel Z590 Chipset : 1 x PCIe 3.0 x16 slot (supports x4 mode) 1 x PCIe 3.0 x1 slots
Wireless and Bluetooth	Intel Wi-Fi 6E 2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax/az) Supports 2.4/5/6GHz frequency band Bluetooth v5.2 hardware ready
Storage	Total supports 4 x M.2 slots and 6 x SATA 6Gb/s ports Intel 11th & 10th Gen Processors: M.2_1 slot (Key M), type 2242/2260/2280/22110 - Only Intel 11th Core processors support PCIe 4.0 x4 mode, this slot will be disabled for other CPUs M.2_2 slot (Key M), type 2242/2260/2280 - Intel 11th Core processors support PCIe 4.0 x4 mode - Intel 10th Core processors support PCIe 3.0 x4 mode Intel Z590 Chipset: M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 mode) M.2_4 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 3.0 x4 & SATA modes) 6 x SATA 6Gb/s ports
Audio	ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4082 - Impedance sense for front and rear headphone outputs - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking - High quality 120 dB SNR stereo playback output and 113 dB SNR recording input - Supports up to 32-Bit/384 kHz playback" Audio Features - SupremeFX Shielding Technology - ESS SABRE9018Q2C DAC/AMP - Gold-plated audio jacks - Rear optical S/PDIF out port - Premium Japanese audio capacitors - Audio cover
USB Ports	Rear USB (Total 10 ports): 2 x Thunderbolt 4 port(s) (2 x USB Type-C) with up to 5V/3A, 15W charging support 6 x USB 3.2 Gen 2 port(s) (6 x Type-A) 2 x USB 2.0 port(s) (2 x Type-A) Front USB (Total 9 ports): 1 x USB 3.2 Gen 2x2 connector(s) (suppport(s) USB Type-C) 2 x USB 3.2 Gen 1 header(s) support(s) additional 4 USB 3.2 Gen 1 ports 2 x USB 2.0 header(s) support(s) additional 4 USB 2.0 ports
I/O Ports	2 x Thunderbolt 4 USB Type-C port(s) 6 x USB 3.2 Gen 2 port(s) (6 x Type-A) 2 x USB 2.0 port(s) (2 x Type-A) 1 x HDMI port 1 x ASUS Wi-Fi Module 2 x Intel I225-V 2.5Gb Ethernet 5 x Gold-plated audio jacks 1 x Optical S/PDIF out port 1 x BIOS FlashBack button 1 x Clear CMOS button
Internal I/O ports	Fan and Cooling related: 1 x 4-pin CPU Fan header(s) 1 x 4-pin CPU OPT Fan header(s) 1 x 4-pin AIO Pump header(s) 3 x 4-pin Chassis Fan header(s) 1 x 4-pin H_AMP Fan header(s) 1 x W_PUMP+ header(s) 1 x 2-pin Water In header 1 x 2-pin Water Out header 1 x 3-pin Water Flow header Power related: 1 x 24-pin Main Power connector 2 x 8-pin +12V Power connector Storage related 4 x M.2 slots (Key M) 6 x SATA 6Gb/s ports USB: 1 x USB 3.2 Gen 2x2 connector (support(s) USB Type-C) 2 x USB 3.2 Gen 1 header(s) support(s) additional 4 USB 3.2 Gen 1 ports 2 x USB 2.0 header(s) support(s) additional 4 USB 2.0 ports Miscellaneous: 3 x AURA Addressable Gen 2 header(s) 1 x AURA RGB header(s) 1 x FlexKey button 1 x Front Panel Audio header (AAFP) 1 x ReTry button 1 x Speaker header 1 x SPI TPM header (14-1pin) 1 x Start button 1 x 10-1 pin System Panel header 1 x Thermal Sensor header
Accessories	Cables: 1 x ARGB RGB extension cable 1 x RGB extension cable 4 x SATA 6Gb/s cables Miscellaneous: 1 x ASUS Wi-Fi moving antennas 1 x M.2 SSD screw package(s) 1 x Q-connector 1 x ROG key chain 1 x ROG logo plate stickers 1 x ROG Graphics card holder 1 x ROG stickers 1 x ROG thank you card Installation Media: 1 x Support DVD Documentation: 1 x User manual
Dimensions	30.5 cm x 24.4 cm (12 x 9.6 inch ) ATX Form Factor
Warranty	3 Years of Brand Warranty
