MSI MPG Z590 Gaming Carbon WiFi motherboard is designed to support Intel 11th and 10th Gen processors for 1200 socket. Combining MSI Core Boost, you can release maximum performance no matter what CPU you use. The board Running at PCI-E Gen4 maximizes performance for the latest SSDs.
The board supports DDR4 memory up to 128GB and speed of 5300MHz. Expand your connectivity with 1x PCIe 4.0 x16 slot, 2x PCIe 3.0 x1 slots, 3x USB 3.2 Gen2 (Type-A), 1x USB-C, 4x USB 2.0 ports and an excellent audio experience for your entertainment with 8 channel 7.1 HD Audio Boost.
MSI DDR4 Boost ensures that you have smooth and optimized gameplay which devoid crashing. With Optimized layout design and a fully isolated memory circuitry the board ensures perfect stability and performance.
2.5Gbps LAN provides incredible data transfer speed faster than general Gigabit LAN. Connect to a high-speed wireless network powered by an Intel Wi-Fi / Bluetooth solution with dedicated high quality Wi-Fi antenna, delivering AX speeds up to 2.4Gbps.
Onboard LEDs for key components will indicate the source of the problem so you know exactly where to look to get it up and running again.

~section~

MSI MPG Z590 Gaming WiFi Motherboard-From TPSTech

MSI MPG Z590 Gaming WiFi Motherboard-From TPSTech

M.2 Shield Frozr

M.2 Shield Frozr is the next generation M.2 thermal solution to avoid this by offering the best thermal protection to make sure that SSD maintains maximum performance.

MSI MPG Z590 Gaming WiFi Motherboard-From TPSTech

Fully Fan Control

Total Fan Control allows you check your primary system characteristics in a simplified graphical interface. You can also set up to 4 temperature targets for CPU and motherboard, which will adjust the fan speeds automatically.

MSI MPG Z590 Gaming WiFi Motherboard-From TPSTech

Lightning Gen 4 M.2

Utilizing 11th Gen Intel processors, MSI Z590 motherboards feature latest Lightning Gen 4 M.2 which is the fastest onboard storage solution on the market with up to 64 Gb/s transfer speed.

MSI MPG Z590 Gaming WiFi Motherboard-From TPSTech

WiFi 6E

Wi-Fi 6E solution supports 6GHz spectrum, Bluetooth 5.2, two-way MU-MIMO and BSS color technology, provide up to 4X network capacity delivering speeds up to 2400Mbps.

MSI MPG Z590 Gaming WiFi Motherboard-From TPSTech

High Bandwidth

2.5Gbps LAN provides incredible data transfer speed faster than general Gigabit LAN. This is a premium solution for demanding users.

MSI MPG Z590 Gaming WiFi Motherboard-From TPSTech

Lightning USB 3.2 Gen2

MPG Z590 series motherboards offer a wide variety of options to connect and boost your USB devices, offering never before seen USB speeds up to 20Gb/s when connecting the Rear USB Type-C.

MSI MPG Z590 Gaming WiFi Motherboard-From TPSTech

Core Boost

Core Boost technology combines MSI’s premium layout and digital power design which allows for faster and undistorted current delivery to the CPU at pin-point precision. Not only supporting multi-core CPU, also creating the perfect conditions for your CPU overclocking.

Samsung CF390 27-inch FHD Curved Gaming Monitor with 1800R curvature -From TPS Tech

DDR4 Boost

MSI conducts thorough memory testing with the most popular memory brands under extreme conditions to ensure your system runs stable no matter what. Our memory partners include brands like Corsair, Crucial, Kingston, G.Skill and many more to optimize memory modules, configurations and even improve overclocking.

Samsung CF390 27-inch FHD Curved Gaming Monitor with 1800R curvature -From TPS Tech

Resizable Bar

Resizable BAR (Re-Size BAR) is an advanced PCI Express feature that enables the CPU to access the entire GPU frame buffer at once and improve performance.

MSI MPG Z590 Gaming WiFi Motherboard-From TPSTech

EZ Debug LED

Onboard LEDs for key components will indicate the source of the problem so you know exactly where to look to get up and running again.

MSI MPG Z590 Gaming WiFi Motherboard-From TPSTech

Overclocking with XMP Profile

The XMP (Extreme Memory Profiles) in MSI BIOS are tested and certified by MSI OC LAB. It is easy to enable with auto power settings to get the best memory speed and stability.

MSI MPG Z590 Gaming WiFi Motherboard-From TPSTech

Audio Boost

From HD-A to USB Interface, twice the DAC format from 32-bit/192kHz to 32-bit/384kHz, deliver the highest sound quality. Keep your sound perfect by transmit your audio with pure digital signal.

~section~

Model	MPG Z590 Gaming Carbon WiFi
CPU Socket	1200
Chipset	Intel Z590 Chipset
Form Factor	ATX
Memory	4x DDR4 memory slots, support up to 128GB Supports 1R 2133/ 2666/ 2933 MHz for 10th Gen Intel CPU (by JEDEC & POR) Supports 1R 2133/ 2666/ 2933/ 3200 MHz for 11th Gen Intel CPU (by JEDEC & POR) Supports Dual-Channel mode Supports non-ECC, un-buffered memory Supports Intel Extreme Memory Profile (XMP)
Graphics	1x HDMI 2.0b with HDR port, supports a maximum resolution of 4K 60Hz 1x DisplayPort 1.4 port, supports a maximum resolution of 4K 60Hz
Expansion Slots	3x PCIe x16 slots -Support PCIe 4.0 for 11th Gen Intel CPU -Support PCIe 3.0 for 10th Gen Intel CPU 2x PCIe 3.0 x1 slots (From Z590 Chipset)
Storage	6x SATA 6Gb/s ports (From Z590 Chipset) 3x M.2 slots (Key M) M2_1 slot (From CPU) Available only on 11th Gen Intel CPU Supports PCIe 4.0 x4 Supports 2242/ 2260/ 2280/ 22110 storage devices M2_21 & M2_32 slot (From Z590 Chipset) Supports PCIe 3.0 x4 Supports SATA 6Gb/s Supports 2242/ 2260/ 2280 storage devices Intel Optane Memory Ready Supports Intel Smart Response Technology for Intel Core processors
LAN	1x Intel I225V 2.5Gbps LAN controller
Audio	Realtek ALC4080 Codec 7.1-Channel High Definition Audio
BackPanel Ports	4x USB 2.0 1x DisplayPort 2x USB 3.2 Gen 1 5Gbps Type-A 1x 2.5G LAN Audio Connectors Flash BIOS Button 1x HDMI 3x USB 3.2 Gen 2 10Gbps Type-A 1x USB 3.2 Gen 2x2 20Gbps Type-C Wi-Fi / Bluetooth Optical S/PDIF Out
Internal I/O Connectors	1x 24-pin ATX main power connector 2x 8-pin ATX 12V power connectors 1x 6-pin PCIE power connector 6x SATA 6Gb/s connectors 3x M.2 slots (M-Key) 1x USB 3.2 Gen 2 10Gbps Type-C port 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports) 2x USB 2.0 Type-A connectors (supports additional 4 USB 2.0 ports) 1x 4-pin CPU fan connector 1x 4-pin water-pump fan connector 6x 4-pin system fan connectors 1x Front panel audio connector 2x System panel connectors 1x Chassis Intrusion connector 1x Clear CMOS jumper 1x TPM module connector 1x TBT connector (supports RTD3) 1x Tuning Controller connector
LED Features	1x EZ LED Control switch 4x EZ Debug LED 1x 2-Digit Debug Code LED 1x 4-pin RGB LED connector 2x 3-pin RAINBOW LED connectors 1x 3-pin CORSAIR LED connector
Operating System	Support for Windows 10 64-bit
Dimension	30.5 cm x 24.4 cm
Warranty	3 Years Brand Warranty
Package Contents	MSI MPG Z590 Gaming Carbon WiFi Motherboard WiFi Antenna M.2 Screws Screwdrivers USB Drive 2x SATA Cables 1to2 RGB LED Extension Y Cable Rainbow RGB LED Extension Cable Cable Stickers MPG Stickers Case Badge Cleaning Brush Reward Program Flyer Registration Card Product Catalog User Manual Installation Guide
