Product Description:
📹 16 Channel Hybrid Recording Supports HDCVI, AHD, TVI, CVBS and IP cameras, making it easy to integrate with existing and new surveillance systems.
💾 Efficient H.265 Video Compression Reduces storage usage while maintaining clear video recording for longer retention periods.
🌐 Expandable IP Camera Support Supports up to 18 IP camera channels with resolutions up to 6MP, providing flexibility for future system expansion.
🚨 Smart Motion Detection Plus Filters human and vehicle events on up to 8 analog channels to help reduce false motion alarms.
📱 Remote Monitoring Made Easy View and manage your surveillance system using iCMOB, gCMOB and KVMS Pro Lite software from supported devices.
The CP PLUS CP-UVR-1601E1-IC2 16 Channel DVR is designed for reliable CCTV recording in homes, offices, retail stores and commercial premises. It supports multiple video formats including HDCVI, AHD, TVI, CVBS and IP cameras for flexible deployment. H.265 dual-stream compression helps optimize storage, while Smart Motion Detection Plus improves event accuracy. With support for up to 18 IP channels, one SATA hard drive up to 16TB and remote viewing through iCMOB, gCMOB and KVMS Pro Lite, it offers an efficient surveillance recording solution.
Product Specifications:
| Specification | Details |
|---|---|
| Brand | CP PLUS |
| Model | CP-UVR-1601E1-IC2 |
| Product Type | Digital Video Recorder (DVR) |
| DVR Channels | 16 Channel |
| Video Input | 16 × BNC |
| Supported Video Formats | HDCVI, AHD, TVI, CVBS, IP |
| Maximum IP Camera Support | Up to 18 Channels |
| Maximum IP Camera Resolution | Up to 6MP |
| Incoming Bandwidth | 64 Mbps |
| Video Compression | H.265, H.264+, H.264 |
| Operating System | Embedded Linux |
| Processor | Industrial-grade Processor |
| Video Output | 1 × HDMI, 1 × VGA |
| Display Split | 1 / 4 / 8 / 9 / 16 |
| Smart Motion Detection | SMD Plus on up to 8 Analog Channels |
| Audio Input | 1 × RCA + 16-Channel BNC (Coaxial Audio) |
| Audio Output | 1 × RCA |
| Two-way Audio | Supported |
| Storage | 1 × SATA HDD, up to 16TB |
| USB Ports | 2 × USB 2.0 |
| Network Interface | 1 × RJ45 (10/100 Mbps Ethernet) |
| Network Protocols | HTTP, HTTPS, TCP/IP, IPv4, RTSP, UDP, SMTP, NTP, DHCP, DNS, DDNS, InstaOn Cloud, ONVIF 21.06, CGI |
| Mobile Viewing | iCMOB, gCMOB |
| CMS Software | KVMS Pro Lite |
| Power Supply | DC 12V / 2A |
| Operating Temperature | -10°C to +55°C |
| Dimensions | 260 × 231.4 × 47.6 mm |
| Weight | 1.42 kg (Without HDD) |
