Deepcool PL650D 650 Watts 80 Plus Bronze ATX 3.0 Non-Modular Power Supply Unit SMPS

Deepcool PL650D 650 Watts 80 Plus Bronze ATX 3.0 Non-Modular Power Supply Unit SMPS

Brand: DEEPCOOL
Rs. 4,669.00
42% off Rs. 4,669.00 Sale Sold out Rs. 7,999.00
Taxes included. Free Shipping.

Product Description:
The PL650D updates DeepCool non-modular PSUs with a 12VHPWR cable and brings them into compliance with INTEL's ATX3.0 standard. These units are 80 PLUS Bronze-verified, come with a 120mm hydro-bearing fan, and will provide stable power for years to come.

NATIVE ATX3.0
Based on INTEL's latest ATX3.0 standard, the PL650D has the ability to provide twice the total system power for 0.1 ms, so power spikes will never be an issue. A native PCIe 5.0 power connector is included and has been rated up to 300 watts.

PREMIUM ELECTROLYTIC CAPACITORS
High-grade electrolytic capacitors allow the PL-D series of PSUs to keep the hold-up time to ≥ 16 ms under full load (100%), and they can easily handle power outages.

ROCK SOLID RELIABILITY
Provides reliable and stable power thanks to a well-designed dual-transistor forward topology. The PL-D utilizes active PFC and DC to DC conversion. The entire unit is made of high-quality parts and can operate at altitudes of up to 5,000 meters above sea level.

PAST, PRESENT AND FUTURE
Equipped with three PCIe, two EPS, and a 16AWG 12VHPWR cable, the PL-D PSUs provide stable and consistent power for legacy and next-generation PCs for the foreseeable future.

BOLD BRONZE
Certified 80 PLUS Bronze, ensuring at least 85% efficiency under typical loads (50%).

EXCEPTIONAL WARRANTY
Standing behind the high standards DeepCool has set for our products, a 5-year limited warranty is included to ensure worry-free service.

Type ATX12V V3.0
80PLUS Certifications 80Plus Bronze
Fan Size 120mm
Fan Bearing Hypro Bearing
Topology Active PFC+DC to DC
Capacitors Chinese Electrolytic Capacitors
Power Good Signal 100-500ms
Hold Up Time ≥16ms
Efficiency ≥85% Under Typical Load(50% Loading)
Protection OPP/OVP/SCP/OTP/OCP/UVP/SIP/NLO
Operation Temperature 0-40°C
Connectors
Main Power Connector (20+4)Pin x 1
CPU(4+4)Pin x 2
PCI-E(6+2)Pin x 1
PCI-E(6+2)Pin x 2
12VHPWR(16Pin) x 1
SATA x 3 + 4Pin Peripheral x 1
Regulatory CE/FCC/CCC/RCM/EAC/
CAN ICES-003(B)/NMB-003(B) /TUV-RH
MTBF 100,000 Hours
Product Dimensions 150×140×86mm (W x L x H)
Warranty 5 Year Warranty
