ARCTIC P12 PWM PST CO 120 mm Black CPU Case Cooling Fan
ARCTIC P12 PWM PST CO 120 mm Black CPU Case Cooling Fan
Couldn't load pickup availability
Couldn't load pickup availability
- Free Shipping
- 7-Days Easy Returns
- Brand Warranty
Product Description:
- ARCTIC CPU Case Fan with P12 PWM PST CO Black 120mm Fan., in which the PWM PST controlled fan is designed to work with upto 1800rpm at a low sound level 0.3 Sone.
- Developed with a motor which is powered by a PWM IC of the newest generation, which allows the new P12 PWM PST CO to run much more efficiently than its predecessors.
- The new P12 PWM PST CO case fan, special emphasis was placed on a focused airstream and thus a high static pressure.
- The P12 PWM PST CO fan speed can be controlled synchronously with all your other fans together. This keeps noise at a minimum while guaranteeing maximum cooling performance when needed.
~section~


High Static Pressure
The new P12 PWM PST CO, special emphasis was placed on a focused airstream and thus a high static pressure, guarantees extremely efficient cooling, even with increased air resistance.

200 To 1800 RPM Via PWM PST
Comes with 4-pin connector, the P12 PWM PST CO fan speed can be controlled synchronously with all your other fans together. This keeps noise at a minimum while guaranteeing maximum cooling performance.

High Quality Bearing
Thanks to the premium quality Japanese dual ball bearing, allows continuous operation 24/7 without the slightest compromise in performancel, make it the perfect choice.

More Efficient Technology
The motor is powered by a PWM IC of the newest generation, which allows the new P12 PWM PST CO to run much more efficiently than its predecessors. This saves energy without compromising the performance.
~section~
Model | ARCTIC P12 PWM PST CO |
Part-Number | ACFAN00121A |
Fan |
|
Size | 120 mm |
Control Type | PWM PST |
Fan Bearing | Dual Ball Bearing |
Connector | 4-Pin-Connector + 4-Pin-Socket |
Performance |
|
Fan Speed | 200 - 1800 rpm |
Airflow | 56.3 CFM/ 95.7 m³/h |
Static Pressure | 2.20 mm H₂O |
Noise Level | 0.3 Sone |
Operating Ambient Temperature | 0 - 40 °C |
Electric Characteristics |
|
Typical Voltage | 12 V DC |
Starting Voltage | 3.9 V |
Current/ Voltage | 0.1 A / 12 V |
Cable Length | 400 mm |
Miscellaneous |
|
Dimensions | 120 x 120 x 25 mm |
Weight | 145 g |
Warranty | 6 Years of Brand Warranty |
