CP PLUS CP-DPS-MD200-12D 20A 240W 12V DC Metal Case Power Supply for CCTV

CP PLUS CP-DPS-MD200-12D 20A 240W 12V DC Metal Case Power Supply for CCTV

Brand: CP PLUS
Regular price Rs. 1,999.00
Regular price 26% off Rs. 2,699.00 Sale price Rs. 1,999.00
Sale Sold out
Quantity
  • 100% Genuine Product
  • Highly ⭐ Rated on Trustpilot & Google
  • > 15 Lakh Orders Fulfilled
Loading Offers...
+ Offers

Product Description:

    🔋 High 240W Power Output Delivers 12V DC output with up to 20A current, making it suitable for powering multiple CCTV cameras from a single power supply.

    🛡️ Built in Protection Includes short circuit, overload and overvoltage protection to help safeguard connected surveillance equipment during operation.

    Wide Input Voltage Support Operates with an input voltage range of 180 to 264V AC, offering stable performance across varying power conditions.

    100% Full Load Tested Factory tested at full load to provide dependable performance for continuous CCTV power applications.

    🏗️ Durable Metal Case Design Metal housing helps protect internal components and is suitable for professional CCTV surveillance installations.

    The CP PLUS CP-DPS-MD200-12D 20A Metal Case Power Supply is a reliable 240W power solution designed for CCTV surveillance systems requiring a stable 12V DC output. With a wide 180 to 264V AC input range, built in short circuit, overload and overvoltage protection, and a durable metal enclosure, it supports dependable operation in security installations. It is an excellent choice for residential, commercial and professional CCTV deployments requiring consistent power delivery.

    Product Specifications:

    Specification Details
    Brand CP PLUS
    Model CP-DPS-MD200-12D
    Product Type Metal Case Power Supply
    Rated Power 240W
    Output Voltage 12V DC
    Output Current 0-20A
    Input Voltage 180-264V AC
    Frequency Range 47-63Hz
    Efficiency 84% (Typical)
    Voltage Adjustment Range 11.4-13.2V
    Voltage Tolerance ±2.0%
    Line Regulation ±1.0%
    Load Regulation ±5.0%
    Ripple & Noise 100mVp-p (Max.)
    Protection Features Short Circuit, Overload, Overvoltage Protection
    Overload Protection 110-200% Rated Output
    Status Indicator LED Indicator
    Operating Temperature -20°C to +40°C
    Dimensions 196 × 114 × 55 mm
    Weight 0.5kg
    Warranty 1 Year Manufacturer Warranty
