Product Description:
Build and customize your own compact computer system to fit your productivity, entertainment, retail business, and creative needs with the Intel NUC 11 Pro NUC11PAHi30Z. Featuring a tall form factor that includes a pre-punched bracket for serial and other I/O ports along with a 2.5" drive bay, this compact desktop system includes a 1.9 GHz Intel Core i3-1115G4 dual-core processor with a 4.1 GHz boost speed and integrated UHD Graphics. The system also supports up to 64GB of DDR4-3200 memory across two SO-DIMM slots, and there are two M.2 solid-state drive slots available. Up to four displays can be connected to the NUC 11 Pro through its dual HDMI 2.0b ports, Thunderbolt 4 port, and Thunderbolt 3 port. Other features include a Gigabit Ethernet port and integrated 802.11ax Wi-Fi to connect to compatible high-speed networks. There also three USB 3.2 Gen 2 Type-A ports that can transfer up to 10 Gb/s. For added flexibility, you can install either a Windows or Linux operating system on the NUC 11 Pro Kit.
11th Gen Intel Core Performance
The NUC 11 Pro includes a 1.9 GHz Intel Core i3-1115G4 dual-core processor that has maximum boost speed of 4.1 GHz and integrated UHD Graphics to quickly run a variety of applications and games.
M.2 Expansion
One M.2 2280 PCIe 4.0 M-key slot is available alongside an M.2 2242 PCIe 3.0 B-key SATA slot for compatible solid-state storage drives.
USB Connectivity
Use the USB 2.0 port to connect a wireless keyboard and mouse adapter while reserving the three USB 3.2 Gen 2 Type-A ports for compatible high-speed peripherals such as external storage drives to transfer up to 10 Gb/s.
Thunderbolt 3
Thunderbolt 3 are hardware interfaces that utilize the reversible USB Type-C connector. Both feature a maximum throughput of 40 Gb/s when used with compatible devices. The connector also transmits data via USB4 at up to 20 Gb/s, and dual-bandwidth DisplayPort 1.2 allows you to connect 4K displays. Additionally, you can daisy chain up to six devices from a single Thunderbolt port.
| Model | NUC11PAHI30Z00 |
| Socket | Soldered-down BGA |
| Board Form Factor | UCFF (4" x 4") |
| Processor | Intel Core i3-1115G4 Processor (6M Cache, up to 4.10 GHz) |
| Cores | 2 |
| Threads | 4 |
| Boost Frequency | 4.10 GHz |
| TDP | 40 W |
| Supported Operating System | Windows 10, 64-bit |
| Memory and Storage | |
| Max Memory Size | 64 GB |
| Memory Type | DDR4-3200 1.2V SO-DIMM |
| Max Memory Channels | 2 |
| Included Storage | No Pre-Installed Storage |
| Internal Storage Form Factor | M.2 Card Slot |
| Processor Graphics | |
| Integrated Graphics | Yes |
| Graphics Output |
HDMI 2.0a USB-C (DP1.4) MiniDP 1.4 |
| Displays Supported | 4 |
| Expansion Options | |
| PCI Express Revision | Gen4 |
| PCI Express Configurations | M.2 slot with PCIe X4 lanes |
| M.2 Card Slot (storage) | 22 x 80 |
| I/O Specifications | |
| USB Ports | 3 |
| Audio | Front panel: 3.5mm headphone/mic jack |
| Integrated LAN | Intel Ethernet Controller i225-V |
| Integrated Bluetooth | Yes |
| Miscellaneous | |
| Dimensions | 117 x 112 x 51mm |
| Warranty | 3 Years of Brand Warranty |
