Intel NUC 12 Pro Kit NUC12WSKi70Z Mini PC with Intel Core i7 (No Pre-Installed Storage & Memory)

Intel NUC 12 Pro Kit NUC12WSKi70Z Mini PC with Intel Core i7 (No Pre-Installed Storage & Memory)

Brand: Intel
Regular price Rs. 48,999.00
Sale price 33% off Rs. 48,999.00 Sale Sold out Regular price Rs. 73,000.00
Taxes included. Free Shipping.

Product Description:
  • Leveraging Intel's 14nm process technology and optimizations, the NUC 12 Pro Kit NUC12WSKI70Z Mini PC is equipped with 12 core 10th Gen Intel i7 processor with base clock frequency of 1.80 GHz and can be pushed up to 4.70 GHz.
  • The Intel NUC12WSKI70Z NUC kit gives great visual immersion with integrated graphics processor, supporting 2 displays with HDMI.
  • Comes with 2x front 2x USB 3.2, 2x rear (1x USB 3.2, 1x USB 2.0) and 2x USB 2.0 for extended connectivity.
  • The system is designed to support Windows 11 & 10 64-Bit versions, Ubuntu and Linux with support for memory upto 64GB DDR4 RAM and M.2 & 2.5-inch storage options, making perfect for everyday computing tasks, delivering the performance they need.
  • Intel NUC is a mini PC with the power of a desktop, packing features for entertainment, gaming, and productivity in a 4x4 form factor. Enjoy immersive media experience and responsive interaction while consuming a small amount of power relative to a full-sized PC.

~section~

Model NUC12WSKI70Z
Socket Soldered-down BGA
Board Form Factor UCFF (4" x 4")
Processor Intel Core i7-1260P Processor (12M Cache, up to 4.70 GHz)
Cores 12
Threads 16
Base Frequency 1.80 GHz
Boost Frequency 4.70 GHz
TDP 35 W
Supported Operating System Windows 11, Windows 10 Home, Windows 10 IoT Enterprise, Red Hat Linux, Ubuntu 20.04 LTS
Memory and Storage
Included Memory No Pre-Installed Memory
Max Memory Support 64GB
Memory Type DDR4-3200 1.2V SO-DIMM
Max Memory Channels 2
Included Storage No Pre-Installed Storage
Internal Storage Form Factor M.2 and 2.5-inch Drive
Processor Graphics
Grpahics Intel Integrated Graphics
Graphics Output 2 x HDMI
Displays Supported 2
Expansion Options
PCI Express Revision Gen4 (m.2 22x80 slot)
Gen 3 (otherwise)
PCI Express Configurations PCIe x4 Gen 4: M.2 22x80 (key M)
PCIe x1 Gen 3: M.2 22x42 (key B)
PCIe x1: M.2 22x30 (key E)
M.2 Card Slot (wireless) 22x30 (E)
M.2 Card Slot (storage) 22x80 NVMe (M); 22x42 SATA (B)
I/O Specifications
USB Ports 4
USB Configuration Front: 2x USB 3.2
Rear: 1x USB 3.2, 1x USB 2.0
Internal: 1x USB 3.2 on m.2 22x42 (pins), 2x USB 2.0 (headers)
Total SATA Ports 1
Audio Front panel: 3.5mm headphone/mic jack
Integrated LAN Intel Ethernet Controller i225-V
Integrated Wireless Intel Wi-Fi 6E AX211(Gig+)
Integrated Bluetooth Yes
Miscellaneous
Additional Headers Front_panel (PWR, RST, 5V, 5Vsby, 3.3Vsby); Internal 2x2 power connector
Dimensions 117 x 112 x 54mm
Warranty 3 Years of Brand Warranty
