LENOVO Compatible 65W 20V 7.4 mm Pin Laptop Charger Adapter
LENOVO Compatible 65W 20V 7.4 mm Pin Laptop Charger Adapter
Compatibility check is must for dispatch.
- Free Pan-India Shipping
- Easy 7-Day Returns
- GST Invoice on Every Order
- 100% Genuine, Brand New & Sealed
- Original Manufacturer Warranty
- Trusted Since 2014 · 15 Lakh+ Orders
Couldn't load pickup availability
The Perfect Partner for Your Laptop on the Go
Always on the go? Stop lugging your adapter back and forth between home and office. Get a second adapter for your laptop or Tablet and keep one in the office and one for home or travel.
The 7.4 mm pin laptop adapter for select Lenovo Laptops comes with 65W output power and 3.25A output current.
This 20V adapter is specially designed to meet the power needs of your Lenovo laptop.
Low ripple operating noise, High-efficiency power conversion ratio, Over Voltage, Over Current, Short circuit protection.
Backed by standard full 12-month replacement warranty, the adapter is also RoHS and CE certified.
Troubleshooting Adapter Issues
The adapter cable and power cables may get frayed or cut, and wires may become exposed at either end of the cables. This may be due to the way the cable is wrapped around the adapter, or if the cable is subject to undue stress. If the damage is severe enough to expose wires, you should discontinue using the adapter. To check the adapter, cables, and adapter port on the laptop for any damages:
- Unplug the adapter from the wall outlet.
- Unplug the adapter from the PC.
- Check the adapter and cables (including the power cable) for signs of physical damage or overheating.
- Check if the pin inside the plug or adapter port is bent, broken, or damaged.
- Unplug the adapter from the wall outlet.
- Connect another device on the wall outlet to verify if the wall outlet is working correctly.
- Try a known-good wall outlet.
- Plug the adapter directly to the wall outlet.
Bypass any power regulators like surge protectors, UPS (uninterruptible power supply), power splitters, etc.
- Unplug the adapter from the wall outlet.
- Disconnect any external peripherals that are connected to the PC.
- Remove the battery. Refer to the User Manual of the PC for instructions on how to remove the battery.
If the laptop PC has a non-removable battery, skip this step. - Press and hold the Power button for 30 seconds to drain a residual power from the PC.
- Connect the battery.
- Plug the adapter to the PC.
- Turn on the PC.
- Unplug the adapter from the wall outlet.
- Unplug the adapter from the PC.
- Disconnect the power cable from the adapter.
- Connect the power cable firmly to the adapter.
The BIOS is firmware that is embedded onto the System Board of your computer. Updating the BIOS to the latest version may help the PC recognize the adapter. Updating the BIOS to the latest version requires the laptop PC to be powered by the adapter and battery.
| Product Type | Laptop Adapter |
| Pin Size | 7.4 mm |
| Power Output | 20V @ 3.25A |
| Power Capacity | 65 Watt |
| Compatible Part Numbers | 40Y7630 40Y7659 40Y7660 40Y7661 40Y7662 40Y7663 40Y7664 40Y7665 40Y7667 40Y7668 40Y7669 40Y7670 40Y7671 40Y7672 40Y7673 40Y7674 92P1111 92P1154 92P1158 PA-1650-161 92P1159 92P1160 PA-1650-171 92P1211 92P1212 92P1104 92P1110 92P1211 93P5026 PA-1900-171 92P1111 |
| Compatible Model Numbers | LENOVO 3000 C100 LENOVO 3000 C200 LENOVO 3000 N100 LENOVO 3000 N200 LENOVO 3000 V100 LENOVO 3000 V200 LENOVO E30 LENOVO E40 LENOVO E50 LENOVO Edge 11 Series LENOVO Edge 13 Series LENOVO Edge 14 Series LENOVO Edge 15 Series LENOVO Edge E10 Series LENOVO Edge E120 Series LENOVO Edge E125 Series LENOVO Edge E130 Series LENOVO Edge E30 Series LENOVO Edge E320 Series LENOVO Edge E325 Series LENOVO Edge E330 Series LENOVO Edge E335 Series LENOVO Edge E40 Series LENOVO Edge E420 Series LENOVO Edge E430 Series LENOVO Edge E520 Series LENOVO Edge E530 Series LENOVO Edge E535 Series LENOVO Edge E545 Series LENOVO S230U LENOVO SL300 LENOVO SL310 LENOVO SL400 LENOVO SL410 LENOVO SL500 LENOVO SL510 LENOVO T400 LENOVO T410 LENOVO T420 LENOVO T430 LENOVO T500 LENOVO T510 LENOVO T520 LENOVO T530 LENOVO T60 LENOVO T60P LENOVO T61 LENOVO T61P LENOVO ThinkPad Edge E30 LENOVO ThinkPad Edge E40 LENOVO ThinkPad Edge E50 LENOVO ThinkPad L412 LENOVO Thinkpad L412 Series LENOVO Thinkpad L420 Series LENOVO Thinkpad L430 Series LENOVO ThinkPad L512 LENOVO Thinkpad L512 Series LENOVO Thinkpad L520 Series LENOVO Thinkpad L530 Series LENOVO Thinkpad R400 Series LENOVO Thinkpad R500 Series LENOVO Thinkpad R60 Series LENOVO Thinkpad R60E Series LENOVO Thinkpad R61 Series LENOVO Thinkpad R61E Series LENOVO ThinkPad R61I LENOVO ThinkPad SL410 LENOVO ThinkPad SL410K LENOVO ThinkPad SL510 LENOVO ThinkPad SL510K LENOVO ThinkPad T400s LENOVO ThinkPad T410 LENOVO ThinkPad T410i LENOVO ThinkPad T410s LENOVO ThinkPad T510 LENOVO ThinkPad T510i LENOVO ThinkPad X100e LENOVO ThinkPad X201 LENOVO ThinkPad X201 Tablet LENOVO ThinkPad X201S LENOVO W500 LENOVO W510 LENOVO W520 LENOVO W530 LENOVO W700 LENOVO W701 LENOVO X100E LENOVO X120E LENOVO X121E LENOVO X130E LENOVO X131E LENOVO X200 LENOVO X200S LENOVO X201 LENOVO X220 LENOVO X230 LENOVO X300 LENOVO X301 LENOVO X60 LENOVO X61 LENOVO Z60 LENOVO Z60M LENOVO Z61 LENOVO Z61E LENOVO Z61T |
| Warranty | 1 Year National Warranty |
| Package Contents | Lapcare 65W Laptop Adapter for Select Lenovo Laptops |
