Synology SA6400 12-Bay Rackmount NAS Storage Server
Synology SA6400 12-Bay Rackmount NAS Storage Server
- Free Shipping (optional Express Shipping)
- Comes with 7-Days Returns Policy
- Original Brand Warranty
Product Description:
Product Specifications:
| Specification | Details |
|---|---|
| Brand | Synology |
| Model | SA6400 |
| Product Type | Rackmount NAS Storage Server |
| System Memory | 32 GB DDR4 ECC RDIMM |
| Processor | AMD EPYC 7272 |
| CPU Quantity | 1 |
| CPU Cores | 12 |
| CPU Architecture | 64-bit |
| Processor Frequency | 2.9 GHz (Base), 3.2 GHz (Turbo) |
| System Memory | 32 GB DDR4 ECC RDIMM |
| Memory Module Pre-installed | 32 GB × 1 |
| Total Memory Slots | 16 |
| Maximum Memory Capacity | 1024 GB (64 GB × 16) |
| Drive Bays | 12 |
| Maximum Drive Bays with Expansion Unit | 108 (with 8 × RX1223RP Expansion Units) |
| Hot Swappable Drive | Yes |
| Form Factor | 2U Rackmount |
| Drive Bays | 12 |
| Drive Type | 3.5-inch SATA HDD, 2.5-inch SATA SSD |
| Maximum Drive Bays | 108 |
| Maximum Local User Accounts | 15,360 |
| Maximum Local Groups | 512 |
| Maximum Shared Folder | 512 |
| Maximum Shared Folder Sync Tasks | 32 |
| Maximum Single Volume Size | Up to 1 PB (64 GB memory required, RAID 6 groups only) |
| Maximum Internal Volume Number | 256 |
| RAID Support | RAID F1, Basic, JBOD, RAID 0, RAID 1, RAID 5, RAID 6, RAID 10 |
| Network Ports | 4 × 1GbE RJ-45, 2 × 10GbE RJ-45, 1 × Out-of-Band Management LAN |
| PCIe Expansion | 2 × PCIe Gen3 x8 Slots (x8 Link) |
| USB Ports | 2 × USB 3.2 Gen 1 |
| Expansion Port | 8 × Expansion Ports |
| Power Supply | Redundant Power Supply Units |
| Noise Level | Not specified by the manufacturer |
| Dimensions (H × W × D) | 88 × 482 × 724 mm |
| Operating System | Synology DiskStation Manager (DSM) |
| Part Number | SA6400 |
| Country of Origin | Taiwan |
| Net Weight | 16.5 kg |
| Warranty | 5 Years Limited Warranty |
