Syrotech GPON OLT 4 Port SY-GPON-4OLT with 1.25Gbps Uplink and 2.5Gbps Downlink
Syrotech GPON OLT 4 Port SY-GPON-4OLT with 1.25Gbps Uplink and 2.5Gbps Downlink
Couldn't load pickup availability
- Free Shipping (optional Express Shipping)
- Comes with 7-Days Returns Policy
- Original Brand Warranty
Product Description:
🔌 4 Fixed PON Ports: Supports up to 1:128 splitting ratio for high-density deployments
🚀 High-Speed Transmission: Downlink at 2.5Gbps and uplink at 1.25Gbps for efficient bandwidth usage
🔒 Advanced Security: ONU authentication, ACL access control, and PON interface encryption
🛠️ Flexible Uplink Options: 2 GE Copper + 2 SFP/SFP+ ports supporting 1G/10G transceivers
📡 Robust Standards Compliance: ITU-T G.984/G.988, IEEE 802.1Q VLAN, RSTP, and OMCI support
🧠 Smart Management: CLI, SNMP, Telnet, EMS, and TFTP-based software upgrades
The SYROTECH SY-GPON-4OLT is a high-density rack-mounted GPON OLT designed for scalable fiber deployments. With 4 fixed PON ports and support for up to 1:128 splitting ratio, it ensures efficient bandwidth distribution and seamless connectivity. Equipped with advanced QoS, VLAN, and security features, it meets ITU-T standards and supports hybrid ONU networks. Ideal for ISPs and enterprise networks, it offers flexible uplink options and robust management capabilities.
Product Specifications:
| Specification | Details |
| Model | SY-GPON-4OLT |
| PON Ports | 4 Fixed Slots |
| Uplink Ports | 2 GE (Copper) + 2 SFP/SFP+ (1G/10G) |
| Splitting Ratio | Up to 1:128 |
| Transmission Rate | Downlink 2.5Gbps / Uplink 1.25Gbps |
| Standards Supported | ITU-T G.984/G.988, IEEE 802.1Q, 802.1D, 802.3x |
| QoS Features | WRR, SP, FIFO, IEEE 802.1p, CoS |
| Security Features | ONU Authentication, ACL, Port Isolation |
| Management Interfaces | CLI, SNMP, Telnet, EMS |
| Power Supply | AC 90–240V / DC 36–72V, Dual Input, Hot Swap |
| Installation Type | Standard 19-inch Rack-Mount |
| Operating Temperature | 0°C to 45°C |
| Storage Temperature | -40°C to 80°C |
| Dimensions (W×D×H) | 442 × 200 × 44 mm |
| Country of Origin | China |
| Warranty | 1 Year |
| Weight | 4.25 Kg |
