Syrotech SY-GPON-1010-DONT XPON ONU with 1GE Port and Voice Support
Syrotech SY-GPON-1010-DONT XPON ONU with 1GE Port and Voice Support
Couldn't load pickup availability
- Free Shipping (optional Express Shipping)
- Comes with 7-Days Returns Policy
- Original Brand Warranty
Product Description:
š Interface Support: 1GE + 1POTS port for high-speed internet and voice connectivity
š Dual Mode Detection: Automatically detects and switches between EPON and GPON modes
š Advanced Security: Built-in firewall, MAC filtering, ACL, and URL-based access control
š VoIP Ready: Supports SIP protocol with codecs like G.711, G.729, and features like call forwarding, hold, and conferencing
āļø Robust Management: Full remote management via Syrotech OLT using OAM/OMCI, TR069, Telnet, and Web
š High Performance: Realtek chipset with IPv4/IPv6 dual stack, QoS, VLAN, and multicast support
The Syrotech SY-GPON-1010-DONT is a high-performance XPON ONU designed for FTTH deployments and triple-play services. Featuring 1GE and 1POTS ports, it supports both EPON and GPON modes with automatic detection. Powered by a reliable Realtek chipset, it ensures seamless voice and data transmission with advanced VoIP and firewall capabilities. Its compact design, remote management support, and compliance with ITU-T G.984.x standards make it ideal for modern fiber networks.
Product Specifications:
| Specification | Details |
| Interface | 1GE + 1POTS |
| Indicators | PWR, PON, LOS, WAN, LAN, PHONE |
| Dimensions | 100mm Ć 92mm Ć 29.5mm |
| Net Weight | 0.11 Kg |
| Operating Temperature | 0Ā°C to +55Ā°C |
| Operating Humidity | 10% to 90% (non-condensed) |
| Storage Temperature | -30Ā°C to +60Ā°C |
| Storage Humidity | 10% to 90% (non-condensed) |
| Power Adapter | DC 12V/1A (external AC-DC adapter) |
| Power Consumption | ā¤10W |
| PON Interface | 1XPON port (EPON PX20+ / GPON Class B+) |
| Transmission Distance | Up to 20KM |
| Wavelength | Tx: 1310nm, Rx: 1490nm |
| VoIP Features | SIP, G.711/G.729, Echo Cancellation, FAX, etc |
| Management Protocols | OAM/OMCI, Telnet, Web, TR069 |
| Country of Origin | China |
| Model Number | SY-GPON-1010-DONT |
| Warranty | 3 Year |
| Weight | 0.11 Kg |
