TP-Link Omada TL-SG2210MP 10 Port Gigabit Smart Switch with 8-Port PoE+

TP-Link Omada TL-SG2210MP 10 Port Gigabit Smart Switch with 8-Port PoE+

Brand: TP-Link
Rs. 9,350.00
54% off Rs. 19,999.00 Rs. 9,350.00
Sale Sold out
  • 100% Genuine Product
  • Highly ⭐ Rated on Trustpilot & Google
  • > 15 Lakh Orders Fulfilled

Product Description:

PoE+ Capability: This switch features eight 802.3af/at-compliant PoE+ ports, each capable of delivering up to 30W of power. This makes it ideal for powering devices such as IP cameras, access points, and IP phones through a single Ethernet cable.

Generous PoE Budget: With a total PoE power budget of 150W, it can support multiple PoE devices simultaneously, making it suitable for small to medium-sized surveillance and networking setups.

Full Gigabit Ports: Includes eight gigabit PoE+ ports and two gigabit SFP slots, providing high-speed connections and flexibility for fiber uplink connections.

Advanced Management Features: Integrated into the Omada SDN platform, it offers centralized cloud management, Zero-Touch Provisioning (ZTP), and intelligent monitoring, making network management more convenient and efficient.

Robust Security and QoS: Supports advanced security strategies like IP-MAC-Port Binding, ACL, and 802.1X, along with L2/L3/L4 QoS and IGMP snooping to optimize voice and video applications.

Model TL-SG2210MP
Standards and Protocols IEEE 802.3i
IEEE 802.3u
IEEE 802.3ab
IEEE802.3z
IEEE 802.3ad
IEEE 802.3x
IEEE 802.3af
IEEE 802.3at
IEEE 802.3az
IEEE 802.1d
IEEE 802.1s
IEEE 802.1w
IEEE 802.1q
IEEE 802.1x
IEEE 802.1p
Interface 8× 10/100/1000 Mbps RJ45 Ports, all supporting PoE+ (Auto-Negotiation/Auto MDI/MDIX)
2× 100/1000 Mbps SFP Slots
Network Media
10BASE-T: UTP/STP category 3, 4, 5 cable (maximum 100m)
100BASE-TX/1000Base-T: UTP/STP category 5, 5e or above cable (maximum 100m)
100BASE-FX: MMF, SMF
1000BASE-X: MMF, SMF
Fan Quantity 1
PoE Ports (RJ45) Standard: 802.3at/af compliant
PoE+ Ports: 8 Ports
PoE Power Budget: 150 W*
Power Supply 100-240V AC, 50/60Hz
Max. Power Consumption V1: 173.9 W (110 V/60 Hz) (with 150 W PD connected); 12.2 W (110 V/60 Hz) (no PD connected)
V2: 169.5 W (220 V/50Hz) (with 150 W PD connected)
V3: 175.3 W (110 V/60Hz) (with 150 W PD connected)
V4: 174.2 W (110V/60Hz) (with 150 W PD connected)
Max Heat Dissipation
V1: 41.63 BTU/h (with no PD connected); 539.35 BTU/h (with 150 W PD connected)
V2: 578.42 BTU/hr (220V/50 Hz) (with 150 W PDconnected)
V3: 597.8 BTU/hr (110 V/60 Hz) (with 150 W PD connected)
V4: 594.46 BTU/hr (110V/60Hz) (with 150 W PD connected)
Switching Capacity 20 Gbps
Packet Forwarding Rate 14.9 Mpps
Advanced Features
Automatic Device Discovery
Batch Configuration
Batch Firmware Upgrading
Intelligent Network Monitoring
Abnormal Event Warnings
Unified Configuration
Reboot Schedule
Dimensions 294 x 180 x 44 mm
Package Content
TL-SG2210MP
Power Cord
Installation Guide
Rackmount Kit
Rubber Feet
Warranty
3 Year Brand Warranty
