- The DS9208 sports a new sleek contemporary design that is at home in either environment. And with the most compact footprint in this class, it can fit in the most space constrained areas like the POS in a boutique to the ticket window at a train station.
- It comes with picklist mode the select and scan a single bar code from a bar code menu or “picklist” is ideal for items that are too small for bar code labels such as nuts and bolts in a hardware store to tiny cosmetic brushes.
- It can read the most common 1D and 2D bar codes on a wide variety of surfaces — from paper labels to cell phone displays. Integrated Electronic Article Surveillance (EAS) functionality eliminates the need to purchase and manage a standalone EAS system.
- Protects productivity in noisy environments, such as theaters, airports and restaurants by providing both visual and audible confirmation of successful scans; convenient side trigger allows users to adjust beeper volume on-the fly.
Omnidirectional Hands-free Scanner
Whether you need to scan printed bar codes on paper labels or mobile bar codes on the screen of a mobile phone, with the DS9208, you’ll be ready. You get the versatility to scan any 1D or 2D bar code from the printed labels in retail that identify product and pricing at the register to mobile coupons, mobile gift and loyalty cards, boarding passes and even theater tickets. And the DS9208 provides all the features you need to keep your workers productive like industry-leading scanning speed, true point-and-shoot scanning simplicity no need to align bar code and scanner and hands-free and handheld flexibility.
Go Anywhere Design
Maybe your retail store has a trendy decor or maybe your counter space is extremely limited. The DS9208 sports a new sleek contemporary design that is at home in either environment. And with the most compact footprint in this class, the DS9208 can fit in the most space constrained areas from the POS in a boutique to the ticket window at a train station.
Select and scan a single bar code from a bar code menu or “picklist”, this scanner is ideal for items that are too small for bar code labels such as nuts and bolts in a hardware store to tiny cosmetic brushes. The handheld and hands-free modes helps to save your time.
|Product Type||Omnidirectional Scanner|
|Light Source||Aiming pattern: single dot, 625nm LED
Illumination: 630nm LEDs
|Swipe Speed||Up to 90 in./2.3 m per second|
|Min Print Contrast||25% minimum reflective difference|
|Graphics Format Support||Images can be exported as Bitmap, JPEG or TIFF|
|Image Transfer Speed||USB 2.0: Up to 12 Megabits/second
RS-232: Up to 115 kb/second
|Nominal Working Range||Code 39 – 5 mil: 0 – 4.5 inch
UPC/EAN – 10 mil (80%): 0 – 8.5 inch
UPC/EAN – 13 mil (100%): 0 – 10.5 inch
PDF417 – 6.6 mil: 0 – 3.8 inch
Datamatrix – 10 mil: 0 – 4.7 in. (0 – 11.9 cm)
|Interface||USB, RS-232, RS-485 (IBM 46xx Protocols), Keyboard Wedge|
|Dimensions||5.512 x 3.232 x 3.150 inch|
|Voltage & Current||Idle: 5 ± 10% VDC @ 150ma average
Scanning: 5 ± 10% VDC @ 230ma average
|Decode Capability||1D: UPC/EAN (UPCA/UPCE/UPCE1/EAN-8/EAN-13/JAN-8/JAN-13 plus supplementals, ISBN (Bookland), ISSN, Coupon Code), Code 39 (Standard, Full ASCII, Trioptic,Code 32 (Italian Pharmacode), Code 128 (Standard, Full ASCII, UCC/EAN-128, ISBT-128 Concatenated), Code 93, Codabar/NW7, 2 of 5 (Interleaved 2 of 5, Discrete 2 of 5, IATA, Chinese 2 of 5, Matrix 2 of 5, Code 11), MSI Plessey, GS1 DataBar Omnidirectional, Truncated, Stacked, Stacked Omnidirectional, Limited, Expanded,Expanded Stacked)
PDF417 (and variants): PDF417 (Standard, Macro), MicroPDF417(Standard, Macro), Composite Codes (CC-A,CC-B, CC-C)
2D: TLC-39, Aztec (Standard, Inverse), MaxiCode, DataMatrix/ECC 200 (Standard, Inverse), QR Code (Standard, Inverse, Micro)
|Operating Temp||0° to 40° C|
